EMC VNX Series Parts Location Manual page 49

Figure 41 shows an example of a 4U, 60 DAE with the top cover open showing the disk
drives, LCCs, and the fan control modules (or fans).
Figure 41 4U, 60 DAE (with top cover open)
Figure 42 shows an example of the full interior view of a 4U, 60 DAE.
Disk
Fan
Figure 42 4U, 60 DAE (interior view)
The ICMs and power supplies shown in
DAE. "4U, 60 (2.5- or 3.5-inch) DAE ICM and power supply" on page 54
information.
Top cover
ICM
LCC
Power Supply
Figure 42 are accessed from the rear of the 4U, 60
EMC VNX7500 Parts Location Guide
Disk-array enclosure (DAE)
VNX-000649
CL4658
provides more
49
