Rear view
The part number label for the Data Mover CPU module in
Table 11.
Table 11 Data Mover CPU part number
Part number label
location
(Figure 17 on
page 20) Part number
110-113-724B
303-113-700B
Figure 18 shows the rear view of a 2U Data Mover enclosure.
Figure 18 Data Mover enclosure rear view
Table 12 shows the part number label location, part number, description, and whether it
is a FRU or CRU.
Table 12 Data Mover enclosure part numbers rear view
Part number label
location
(Figure 18) Part number
1 100-562-178
2 110-130-100B
3 303-092-102B
4 303-122-100A
Figure 17 on page 20
Description
Data Mover 2.8-GHz CPU module
with 24 GB of memory
Data Mover 2.8-GHz CPU module
without memory
1 2 3
Description
Data Mover enclosure (empty)
Management module (for a closer
view, see Figure 19 on page
Four-port 8-Gb/s Fibre Channel (FC)
I/O Module (for a closer view, see
Figure 20 on page 25)
Two-port 1-Gb/s copper plus
two-port 1-G/bs optical I/O Module
(for a closer view, see Figure 21 on
page 26)
EMC VNX7500 Parts Location Guide
Data Mover enclosure
is listed in
FRU CRU

4 5
CNS-001724
FRU CRU

 
23)
 
 
