Disk-array enclosure (DAE)
48 EMC VNX7500 Parts Location Guide
If the rack is provided with stabilizing devices, install the stabilizers before mounting or
servicing the DAE in the rack. The
information.
1
1
2
2
Figure 39 4U, 60 DAE (unlocking top, front ring pull latch mechanism and bottom slide extension
release levers)
Figure 40 shows an example of a 4U, 60 DAE with the top cover closed.
Top cover
Figure 40 4U, 60 DAE (with top cover closed)
To gain access to the disk drives, LCCs, and fan control modules (after sliding the DAE out
of the rack), you slide the top cover toward the rear of the DAE.
Replacing a DAE document for the DAE provides more
CL4663
VNX-000656
