Data Mover enclosure

Data Mover CPU module

EMC VNX7500 Parts Location Guide

To access the Data Mover CPU, you must first remove the power supply/cooling fan

modules

(Figure

16).

Figure 16 Example of the Data Mover power supply/cooling fan module removal

Figure 17

shows the Data Mover CPU module partially removed from the front of the Data

Mover enclosure with the two power supply/cooling fan modules set aside.

Power/cooling modules

Part Number (P/N) label

Figure 17 Example of the Data Mover CPU being removed from a Data Mover enclosure

Data Mover CPU

CL3972

Data Mover enclosure

CNS-001683
