INTRODUCTION

The manufacturer, assembler, and importer are responsible for the safety, re-
liability and performance of the unit only if:
- installation, calibration, modification and repairs are carried out by qualified
authorized personnel
- electrical installations are carried out according to the appropriate require-
ments such as IEC364
- equipment is used according to the operating instructions
Installation manual
Planmeca manufactures two versions of the Planmeca
Proline XC X-ray:
-the Planmeca Proline XC Panoramic X-ray
-the Planmeca Proline XC Pan/ Ceph X-ray.
This guide contains all the information required to set up
and calibrate both versions of the Planmeca Proline XC
X-ray.
NOTE You may also need the Planmeca Proline XC X-
ray unit's technical manual (publication number
10010942) during installation. The alignment in-
structions are given in technical manual.
Protect yourself from radiation when you are checking
the radiation beam alignment.
WARNING FAILURE TO INSTALL THE X-RAY IN AN AP-
PROVED LOCATION MAY BE DANGEROUS TO
BOTH PATIENT AND OPERATOR.
CAUTION IT IS VERY IMPORTANT THAT THE ROOM IN
WHICH THE X-RAY IS INSTALLED AND THE PO-
SITION FROM WHICH THE USER OPERATES
THE EQUIPMENT ARE CORRECTLY SHIELDED
FROM RADIATION. SINCE RADIATION SAFETY
REQUIREMENTS VARY FROM COUNTRY TO
COUNTRY AND STATE TO STATE IT IS THE RE-
SPONSIBILITY OF THE INSTALLER TO ENSURE
THAT ALL LOCAL SAFETY REGULATIONS ARE
MET.
CAUTION The exposure switch Autoprint and Admark film
marking systems are connected to the X-ray
units Planet connectors. Do NOT connect any
other devices to the Planet connectors.
The display values shown in this guide are only examples
and should not be interpreted as recommended values
unless otherwise stated.
INTRODUCTION
Planmeca Proline XC X-ray unit 1
