13. To change the Sensor Fill-H value, first press the ENTER key. The
value will now be highlighted and you can enter the number using the
F-Keys as you would a 10-digit key pad, with the down arrow to enter
the decimal point. Then, press ENTER again to complete the entry and
store the value into memory.
14. Press the Next Soft Key to proceed to Empty Setting.
15. Empty Setting is the display value when the tank is empty.
16. To change the Empty Setting value, first press the ENTER key. The
value will now be highlighted and you can enter the number using the
F-Keys as you would a 10-digit key pad, with the down arrow to enter
the decimal point. Then, press ENTER again to complete the entry and
store the value into memory.
17. Press the Next Soft Key to proceed to Full Setting.
18. Full Setting is the display value when the tank is full.
19. To change the Full Setting value, first press the ENTER key. The
value will now be highlighted and you can enter the number using the
F-Keys as you would a 10-digit key pad, with the down arrow to enter
the decimal point. Then, press ENTER again to complete the entry and
store the value into memory.
20. Press the Next Soft Key to return to the Config Inputs and Config Outputs screen.
21. Press Exit Soft Key to end configuration.
