Fs G 2 M A1 A2 A3 A4 Nl Nh [Obsolete Command]; Gs G 0 M Nl Nh - Tally Dascom DT-210 Programmer's Manual

Tally Dascom DT-210/230
32 ≤ d ≤ 255
k = (nL + nH × 256)
The entire capacity size = 1KB.
[Description]
Stores the data (d1...dk) in the area from (a1 + a2 × 256 + a3 × 65536 + a4 × 16777216)
to (nL + nH × 256) bytes in the NV user memory.
[Note]
• Frequent write command executions by an NV memory write command may damage
the NV memory. Therefore, it is recommended to limit writing the commands into the
NV memory to less than 10 times a day.
• If the power is turned off or the printer is reset via an interface while this command is
being executed, the printer may go into an abnormal condition. Be careful not to turn
the power off or let the printer be reset via an interface while this command is being
executed.
• While processing this command, the printer may become BUSY while writing the data
to the NV memory and stops receiving data. Therefore, be sure not to transmit data,
including the real-time commands while the printer is BUSY.
FS g 2 m a1 a2 a3 a4 nL nH
[Function] Read from NV user memory
[Format] ASCII
Hex
Decimal
[Range]
m = 0
0 ≤(a1 + a2×256 + a3×65536 + a4×16777216) ≤ 1023
(0 ≤ a1 ≤ 255, 0 ≤ a2 ≤ 3, a3 = 0, a4 = 0)
1 ≤ (nL + nH × 256) ≤ 80 (1 ≤ nL ≤ 80, nH = 0)
[Description]
Transmits the data in the area from (a1 + a2 × 256 + a3 × 65536 + a4 × 16777216) to (nL
+ nH × 256) bytes in the NV user memory.
[Note]
When this command is transmitted, do not transmit the subsequent data until the
status is received.

GS g 0 m nL nH

[Function] Initialize maintenance counter
[Format] ASCII
Hex
Decimal
[Range]
m = 0
(nL + nH × 256) = 20, 21, 50, 70
[Description]
Set the resettable maintenance counter specified by (nL + nH × 256) to 0.
FS g 2 m a1 a2 a3 a4 nL nH
1C 67 32 m a1 a2 a3 a4 nL nH
28 103 50 m a1 a2 a3 a4 nL nH
GS g 0 m nL nH
1D 67 30 m nL nH
29 103 48 m nL nH
Programming Guide V1.1
[obsolete command]
- 48 -
