Tally Dascom DT-210/230
GS ( D pL pH m [a1 b1]...[ak bk])
[Function] Enable/disable real-time command
[Format] ASCII
Hex
Decimal
[Range] 3≤(pL + pH×256) ≤65535 (0≤pL≤255, 0≤pH ≤255)
m = 20
a = 1, 2
b = 0, 1, 48, 49
[Default] b = 1 [when a = 1]
b = 0 [when a = 2]
[Description]
• Enables or disables the real-time command specified by a.
• pL, pH specify (pL + pH × 256) as the number of bytes after pH (m and [a1 b1]...[ak
bk]).
a
1
2
[Note]
If graphics data includes a data string matching DLE DC4 (fn = 1 or 2), it is recommended
to use this command in advance to disable the real-time commands.

GS ( E pL pH fn [parameters])

[Function] Set user setup commands
[Description]
• Controls the user setting modes.
• pL, pH specify (pL + pH ×256) as the number of bytes after pH (fn and [parameters]).
• fn specifies the function.
• [parameters] specify the process of each function.
fn Format
1 GS ( E pL pH fn d1 d2
2 GS ( E pL pH fn d1 d2 d3
5 GS ( E pL pH fn
[a1 n1L n1H] ... [ak nkL nkH]
6 GS ( E pL pH fn a
11 GS ( E pL pH fn a d1...dk
12 GS ( E pL pH fn a
GS (
1D 28 44 pL pH m [ a1 b1 ]...[ ak bk ]
29 40 68 pL pH m [ a1 b1 ]...[ ak bk ]
b
0,48 DLE DC4 fn m t (fn = 1): Not processed (disabled).
1,49 DLE DC4 fn m t (fn = 1): Processed (enabled).
0,48 DLE DC4 fn a b (fn = 2): Not processed (disabled).
1,49 DLE DC4 fn a b (fn = 2): Processed (enabled).
Function No.
1
2
5
6
11
12
Programming Guide V1.1
D pL pH m [ a1 b1 ]...[ ak bk ]
Function
Function name
Change into the user setting mode.
End the user setting mode session.
Set the customized setting values.
Transmit the customized setting values.
Set the configuration item for the serial
interface.
Transmit the configuration item for the
serial interface.
- 20 -
