Tally Dascom DT-210/230
off or do not reset the printer via an interface while this command is being executed.
• While processing this command, the printer may become BUSY while writing data to
the NV memory and stops receiving data.
host computer while the printer is BUSY.
• The printer executes a software reset after processing this command.
• Clear the receiver and print buffers.
• Resets all setting values in RAM (the print area, the character styles, user-defined
characters, and others) that were in effect at power on. (The data in the NV memory are
not reset.)
• NV bit image and NV graphics (GS (L/ GS 8 L) cannot be defined simultaneously. When
this command is executed, all NV graphics are deleted.
GS v 0 m xL xH yL yH d1...dk
GS (L <Function 112 and 50>, which is the upward-compatible command replacing GS v 0, is
recommended to use, since GS v 0 is an obsolete command in the ESC/POS command system.
[Function] Print raster bit image
[Format] ASCII
Hex
Decimal
[Range]
0 ≤ m ≤ 3, 48 ≤ m ≤ 51
1 ≤ (xL+ xH × 256) ≤ 65535 (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 255)
1 ≤ (yL + yH × 256) ≤ 2303 (0 ≤ yL ≤ 255, 0 ≤ yH ≤ 8)
0 ≤ d ≤ 255
k = (xL + xH × 256) × (yL + yH × 256)
[Description]
• Prints a raster bit image using the mode specified by m.
m
0,48
1,49
2,50
3,51
• xL, xH specify the number of bytes in the horizontal direction as (xL + xH × 256).
• yL, yH specify the number of dots in the vertical direction as (yL + yH × 256).
• d specifies the defined data (raster format)
FS g 1 m a1 a2 a3 a4 nL nH d1...dk
[Function] Write to NV user memory
[Format] ASCII
Hex
Decimal
[Range]
m = 0
0≤(a1 + a2×256 + a3×65536 + a4× 16777216) ≤1023
(0 ≤ a1 ≤ 255, 0 ≤ a2 ≤ 3, a3 = 0, a4 = 0)
1 ≤(nL + nH×256) ≤1024 (0 ≤ nL ≤ 255, 0 ≤ nH ≤ 4)
GS v 0 m xL xH yL yH d1...dk
1D 76 30 m xL xH yL yH d1...dk
29 118 48 m xL xH yL yH d1...dk
Mode Vertical direction
Normal
Double-width
Double-height
Quadruple
FS g 1 m a1 a2 a3 a4 nL nH d1...dk
1C 67 31 m a1 a2 a3 a4 nL nH d1...dk
28 103 49 m a1 a2 a3 a4 nL nH d1...dk
Programming Guide V1.1
Therefore, do not to transmit data from the

[obsolete command]

Horizontal direction
180 dpi
180 dpi
90 dpi
90 dpi
180 dpi
90 dpi
180 dpi
90 dpi
- 47 -
