Mechanical Control Commands; Gs V; Esc I [Obsolete Command]; Esc M [Obsolete Command] - Tally Dascom DT-210 Programmer's Manual

Tally Dascom DT-210/230

9 Mechanical Control Commands

GS V

[Function] Select cut mode and cut paper
[Format] <A> ASCII
<B> ASCII
[Range]
<A> m = 0, 1, 48, 49
<B> m = 65, 66, 0 <n ≤ 255
[Description]
Executes paper cutting specified by m.
＜A>
＜B>
[Note]
This printer executes a partial cut (one point left uncut).
ESC i
[Function] Partial cut (one point left uncut)
[Format] ASCII
Hex
Decimal
[Description]
Executes a partial cut of the roll paper.
[Note]
• See GS V <Function A>for details.
• The cutting shape depends on the specification of the mounted auto-cutter.
ESC m
[Function] Partial cut (three points left uncut)
[Format] ASCII
Hex
Decimal
[Description]
Executes a partial cut of the roll paper.
[Note]
• See GS V <Function A>for details.
• The cutting shape depends on the specification of the mounted auto-cutter.
GS V m
Hex 1D 56 m
Decimal 29 86 m
GS V m n
Hex 1D 56 m n
Decimal 29 86 m n
m
0，48 Cuts paper.
1，49
65，66 Feeds paper to (cutting position + [n × (vertical motion unit)]) and
cuts the paper.
ESC i
1B 69
27 105
ESC i
1B 6D
27 109
Programming Guide V1.1
Function
[obsolete command]
[obsolete command]
- 45 -
