Tally Dascom DT-210/230

10 Other Commands

FS p n m
GS ( L <Function 69>, which is the upward-compatible command replacing FS p, is recommended to use,
since FS p is an obsolete command in the ESC/POS command system.
[Function] Print NV bit image
[Format] ASCII
Hex
Decimal
[Range]
1 ≤ n ≤ 255
0 ≤ m ≤ 3, 48 ≤ m ≤ 51
[Description]
Prints NV bit image n using the process of FS q and using the mode specified by m.
m
0,48
1,49
2,50
3,51
FS q n [xL xH yL yH d1...dk]1 ... [xL xH yL yH d1...dk]n
GS ( L <Function 67>, which is the upward-compatible command replacing FS q, is recommended to use,
since FS q is an obsolete command in the ESC/POS command system.
[Function] Define NV bit image
[Format] ASCII
Hex
Decimal
[Range]
1 ≤ n ≤ 255
1 ≤ (xL + xH × 256) ≤ 1023 (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 3)
1 ≤ (yL + yH × 256) ≤ 288 (0 ≤ yL ≤ 255, yH = 0,1)
0 ≤ d ≤ 255
k = (xL + xH × 256) × (yL + yH × 256) × 8
The entire capacity size = 256 KB.
[Description]
• Defines the NV bit image in the NV graphics area.
• n specifies the number of defined NV bit images.
• xL, xH specify the number of bytes in the horizontal direction as (xL+xH ×256).
• yL, yH specify the number of bytes in the vertical direction as (yL + yH × 256).
• d specifies the defined data (column format).
[Note]
• Frequent write command executions by an NV memory write command may damage
the NV memory. Therefore, it is recommended to limit writing the commands into the
NV memory to less than 10 times a day.
• If the power is turned off or the printer is reset via an interface while this command is
being executed, the printer may go into an abnormal condition. Do not turn the power
FS p n m
1C 70 n m
28 112 n m
Mode Vertical direction
Normal 1
Double-width 1
Double-height 9
Quadruple 9
FS q n [xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n
1C 71 n [xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n
28 113 n [xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n
Programming Guide V1.1

[obsolete command]

Horizontal direction
180 dpi
180 dpi
90 dpi
90 dpi
[obsolete command]
180 dpi
90 dpi
180 dpi
90 dpi
- 46 -
