Tally Dascom DT-210/230
<Function 067> GS ( k pL pH cn fn n (cn = 48, fn = 67)
[Function] PDF417: Set the width of the module
[Format] ASCII
Hex
Decimal
[Range] (pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 48
fn = 67
2 ≤ n ≤ 8
[Default]
n = 3
[Description]
Sets the width of the module for PDF417 to n dots
<Function 068> GS ( k pL pH cn fn n (cn = 48, fn = 68)
[Function] PDF417: Set the row height
[Format] ASCII
Hex
Decimal
[Range] (pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 48
fn = 68
2 ≤ n ≤ 8
[Default]
n = 3
[Description]
Set the row height for PDF417 to [n × (the width of the module)]
<Function 080> GS ( k pL pH cn fn m d1...dk (cn = 48, fn = 80)
[Function] PDF417: Store the data in the symbol storage area
[Format] ASCII
Hex
Decimal
[Range] 4 ≤ (pL + pH × 256) ≤ 65535 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 255)
cn = 48
fn = 80
m = 48
0 ≤ d ≤ 255
k = (pL + pH × 256) – 3
[Description]
Stores the PDF417 symbol data (d1...dk) in the symbol storage area
<Function 081> GS ( k pL pH cn fn m (cn = 48, fn = 81)
[Function] PDF417: Print the symbol data in the symbol storage area
[Format] ASCII
Hex
Decimal
[Range] (pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 48
GS ( k pL pH cn fn n
1D 28 6B pL pH cn fn n
29 40 107 pL pH cn fn n
GS ( k pL pH cn fn n
1D 28 6B pL pH cn fn n
29 40 107 pL pH cn fn n
GS ( k
1D 28 6B
29 40 107 pL pH cn fn m d1...dk
GS ( k
1D 28 6B pL pH cn fn m
29 40 107 pL pH cn fn m
Programming Guide V1.1
pL pH cn fn m d1...dk
pL pH cn fn m d1...dk
pL pH cn fn m
- 42 -
