Tally Dascom DT-210/230
fn = 81
m = 48
[Description]
Encodes and prints the PDF417 symbol data in the symbol storage area with GS ( k
<Function 080>.
[Note]
• User must secure the quiet zone (left, right, upward, and downward space areas
defined by the PDF417 symbol specifications) for PDF417 printing.
• In standard mode, symbols higher than 831 dots cannot be printed with this printer.
<Function 082> GS ( k pL pH cn fn m (cn = 48, fn = 82)
[Function] PDF417: Transmit the size information of the symbol data in the symbol storage area
[Format] ASCII
Hex
Decimal
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 48
fn = 82
m = 48
[Description]
Transmit the size information for the encoded PDF417 symbol data in the symbol
storage area with GS ( k <Function 080>.
[Note]
• This function does not print.
• The size information does not include the quiet zone (left, right, upward, and
downward space areas defined by the PDF417 symbol specifications).
<Function 167> GS ( k pL pH cn fn n (cn = 49, fn = 67)
[Function] QR Code: Set the size of module
[Format] ASCII
Hex
Decimal
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 49
fn = 67
1 ≤ n ≤ 16
[Default]
n = 3
[Description]
Set the size of the module for QR Code to n dots
<Function 169> GS ( k pL pH cn fn n (cn = 49, fn = 69)
[Function] QR Code: Select the error correction level
[Format] ASCII
Hex
Decimal
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 49
fn = 69
GS ( k
1D 28 6B
29 40 107
GS ( k
1D 28 6B
29 40 107 pL pH cn fn n
GS ( k pL pH cn fn n
1D 28 6B pL pH cn fn n
29 40 107 pL pH cn fn n
Programming Guide V1.1
pL pH cn fn m
pL pH cn fn m
pL pH cn fn m
pL pH cn fn n
pL pH cn fn n
- 43 -
