Tally Dascom DT-210/230

ESC J n

[Function] Print and feed paper
[Format] ASCII
Hex
Decimal
[Range] 0 ≤n ≤ 255
[Description] Prints the data in the print buffer and feeds the paper [n × (vertical or horizontal motion
unit)].
[Note] The maximum paper feed amount is 1016 mm {40"}.

ESC d n

[Function] Print and feed n lines
[Format] ASCII
Hex
Decimal
[Range] 0 ≤n ≤ 255
[Description] Prints the data in the print buffer and feeds the paper [n × (current line spacing)].
[Note] The maximum paper feed amount is 1016 mm {40"}.
GS ( K pL pH fn [parameters]
[Function] Select print control method(s)
fn
50
97
[Description] • Selects the print control methods.
• pL, pH specify (pL + pH × 256) as the number of bytes after pH (fn and [parameters]).
• fn specifies the function.
• [parameters] specify the process of each function.
ESC J n
1B 4A n
27 74 n
ESC d n
1B 64 n
27 100 n
Format Function No.
GS ( K pL pH fn m
GS ( K pL pH fn m
50 Select the print speed.
97 Select the number of parts for the thermal
head energization.
Programming Guide V1.1
Function name
- 13 -
