Tally Dascom DT-210/230
48 ≤ n ≤ 51
[Default]
n = 48
[Description]
• Selects the error correction level for QR Code.
n
48
49
50
51
<Function 180> GS ( k pL pH cn fn m d1...dk (cn = 49, fn = 80)
[Function]
QR Code: Store the data in the symbol storage area
[Format]
ASCII
Hex
Decimal
[Range]
4 ≤ (pL + pH × 256) ≤ 7092 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 27)
cn = 49
fn = 80
m = 48
0 ≤ d ≤ 255
k = (pL + pH × 256) – 3
[Description]
Store the QR Code symbol data (d1...dk) into the symbol storage area
<Function 181> GS ( k pL pH cn fn m (cn = 49, fn = 81)
[Function]
QR Code: Print the symbol data in the symbol storage area
[Format]
ASCII
Hex
Decimal
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 49
fn = 81
m = 48
[Description]
Encodes and prints the QR Code symbol data in the symbol storage area with GS ( k
<Function 180>.
[Note]
User must secure the quiet zone (left, right, upward, and downward space areas defined
by the QR Code symbol specifications) for QR Code printing.
Function
Select error correction level L
Select error correction level M 1
Select error correction level Q 2
Select error correction level H 3
GS
(
1D
28
29
40
GS
(
1D
28
29
40
Programming Guide V1.1
Reference: Approx. figure of recovery
k
pL pH cn fn m d1...dk
6B
pL pH cn fn m d1...dk
107
pL pH cn fn m d1...dk
k
pL pH cn fn m
6B
pL pH cn fn m
107 pL pH cn fn m
7 %
15 %
25 %
30 %
- 44 -
