Tally Dascom DT-210/230
[Note]
• Frequent write command executions by an NV memory write command may damage
the NV memory. Therefore, it is recommended to limit writing the commands into the
NV memory to less than 10 times a day.
• If the power is turned off or the printer is reset via an interface while this command is
being executed, the printer may go into an abnormal condition. Be careful not to turn
the power off or let the printer be reset via an interface while this command is being
executed.
• While processing this command, the printer is BUSY while writing the data to the NV
memory and stops receiving data. Therefore, be sure not to transmit data, including
the real-time commands, while the printer is BUSY.
• When <Function 1, 6, or 12> is transmitted, the data following must not be
transmitted until the status is received.
<Function 1> GS ( E pL pH fn d1 d2 (fn = 1)
[Function] Change into the user setting mode
[Format] ASCII
Hex
Decimal
[Range] (pL + pH × 256) = 3 (pL = 3, pH = 0)
fn = 1
d1 = 73
d2 = 78
[Description]
Enters the user setting mode and transmits a mode change notice.
<Function 2>GS ( E pL pH fn d1 d2 d3 (fn = 2)
[Function] End the user setting mode session
[Format] ASCII
Hex
Decimal
[Range] (pL + pH × 256) = 4 (pL = 4, pH = 0)
fn = 2
d1 = 79
d2 = 85
d3 = 84
[Description] • Ends the user setting mode and performs a software reset.
• Clears the receive and print buffers.
• Resets all setting values in RAM (the print area, the character styles, and others) that
were in effect at power on. (The data in the NV memory are not reset.)
GS ( E pL pH fn d1 d2
1D 28 45 pL pH fn d1 d2
29 40 69 pL pH fn d1 d2
GS ( E pL pH fn d1 d2 d3
1D 28 45 pL pH fn d1 d2 d3
29 40 69 pL pH fn d1 d2 d3
Programming Guide V1.1
- 21 -
