Tally Dascom DT-210/230
<Function 65> GS ( L pL pH m fn d1 d2 d3 (fn = 65)
[Function] Delete all NV graphics data
[Format] ASCII
Hex
Decimal
[Range] (pL + pH × 256) = 5 (pL = 5, pH = 0)
m = 48
fn = 65
d1 = 67
d2 = 76
d3 = 82
[Description] Delete all NV graphics data.
<Function 66> GS ( L pL pH m fn kc1 kc2 (fn = 66)
[Function] Delete the specified NV graphics data
[Format] ASCII
Hex
Decimal
[Range] (pL + pH × 256) = 4 (pL = 4, pH = 0)
m = 48
fn = 66
32 ≤ kc1 ≤ 126
32 ≤ kc2 ≤ 126
[Description] Delete the NV graphics data defined by the key codes (kc1 and kc2).
<Function 67> GS ( L pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1....dk]b (fn = 67)
[Function] Define the NV graphics data (raster format)
[Format] ASCII
Hex
Decimal
[Range] (pL, pH) for GS ( L: 12 ≤ (pL + pH × 256) ≤ 65535 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 255)
(p1, p2, p3, p4) for GS 8 L:
12 ≤ (p1 + p2 × 256 + p3 × 65536 + p4 × 16777216) ≤ 4294967295
(0 ≤ p1 ≤ 255, 0 ≤ p2 ≤ 255, 0 ≤ p3 ≤ 255, 0 ≤ p4 ≤ 255)
Common parameters for GS ( L and GS 8 L:
m = 48
fn = 67
a = 48
32 ≤ kc1 ≤ 126
32 ≤ kc2 ≤ 126
b = 1 [when single-color print control is selected]
b = 1, 2 [when two-color print control is selected]
1 ≤ (xL + xH × 256) ≤ 8192 (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 32)
1 ≤ (yL + yH × 256) ≤ 2304 (0 ≤ yL ≤ 255, 0 ≤ yH ≤ 9)
GS ( L
1D 28 4C pL pH m fn d1 d2 d3
29 40 76 pL pH m fn d1 d2 d3
GS ( L
1D 28 4C pL pH m fn kc1 kc2
29 40 76 pL pH m fn kc1 kc2
GS ( L pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1...dk]b
1D 28 4C pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1...dk]b
29 40 76 pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1...dk]b
Programming Guide V1.1
pL pH m fn d1 d2 d3
pL pH m fn kc1 kc2
- 5 -
