Control Door Assembly Without Trim - ADC ADG-758 Parts Manual

2
Illus. No. Part No.
1 881053
870011
2 881045*
881046
3 117604
4 150300
5 102600
6 102601
7 102502
8 160005
* Specify color when ordering.
American Dryer Corporation
Qty. Description
1 ADC Logo ONLY
1 Logo Double Adhesive Tape Kit ONLY
1 Control Door
(includes illus. nos. 2, 3, and 8)
1 Stainless Steel Control Door
(includes illus. nos. 2, 3, and 8)
4 Neoprene Sponge Tape (sold by the foot)
4 #10-16 x 1/2" Hex Washer TEK Screw
1 Control Door Rod Support Catch
1 Control Door Retainer Clip
1 Control Door Rod
2 Turn Latch

Control Door Assembly Without Trim
