Sensor Bracket Assemblies

Illus. No. Part No.
1 880251
2 130103
3 153010
4 152000
5 121028
6 122701
112801
7 122605
8 154007
9 150005
10 801425
305007
11 122604
12 122700
13 150301
14 150005
15 130111
16 130100
17 130301
18 130101
19 153010
20 152000
21 840065
22 121028
23 122701
24 122605
840062
25 801418
305007
26 122604
27 122700
122801
28 150301
* As required.
Telephone: (508) 678-9000
Qty. Description
1 1/4" Temperature Sensor Probe Assembly
(includes illus. nos. 1 and 5 through 8)
1 225° F Manual Reset Thermostat
2 #6 Star Washer
2 #6-32 Hex Nut
2 Insulated Terminal ONLY
4 Socket Terminal ONLY
1 Pin/Socket Extraction Tool
1 4-Pin Socket Connector ONLY
2 1/4" Tinnerman Push On Fastener
2 #6-32 x 1/4" Round Head Machine Screw
1 Microprocessor Sensor Bracket Assembly Complete
(includes illus. nos. 1 through 10)
1 Universal Sensor Bracket ONLY
1 4-Pin Connector ONLY
4 Pin Terminal ONLY
2 #8-18 x 7/16" Phillips Pan Head TEK Screw
* #6-32 x 1/4" Phillips Round Head Machine Screw
1 130° F Thermostat
1 150° F Thermostat
1 225° Manual Reset Thermostat
1 180° F Thermostat
* #6 Star Washer
* #6-32 Hex Nut
1 Sensor Jumper ONLY
* Insulated Terminal ONLY
* Socket Terminal ONLY
1 4-Pin Socket Connector ONLY
1 Sensor Bracket Harness Assembly
(includes illus. nos. 22 through 24)
1 Non-Computer Sensor Bracket Assembly Complete (includes thermostats)
(includes illus. nos. 14 through 25)
1 Universal Sensor Bracket ONLY
4-Pin Connector ONLY
* Pin Terminal ONLY
1 Pin/Socket Extraction Tool
2 #8-18 x 7/16" Phillips Pan Head TEK Screw
