PHASE 5
COIN
USER'S MANUAL
American Dryer Corporation
88 Currant Road
Fall River MA 02720-4781 USA
Telephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447
e-mail: techsupport@amdry.com
www.amdry.com
ADC Part No. 112146-56

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gas Electric Steam AD-26 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADC Gas Electric Steam AD-26

  • Page 1 PHASE 5 COIN USER’S MANUAL American Dryer Corporation 88 Currant Road Fall River MA 02720-4781 USA Telephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447 e-mail: techsupport@amdry.com www.amdry.com ADC Part No. 112146-56...
  • Page 2 We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models.
  • Page 3: Table Of Contents

    Table Of Contents SECTION I INTRODUCTION ... 4 Phase 5 Coin Microprocessor Controller (Computer) Features ... 4 SECTION II L.E.D. DISPLAY AND CODES ... 8 SECTION III OPERATING INSTRUCTIONS ... 10 A. Timed Mode ... 10 B. Automatic Mode (Patent No. 4,827,627) ... 11 C.
  • Page 4 PL11 - Time For Amount To Start (tFAS) ... 23 PL12 - Amount To Start (AtSt) ... 23 PL13 - Minimum Amount For Additional Time (AFAT) ... 23 PL14 - Maximum Time For Automatic Dry (Adrt) ... 23 PL15 - Anti-Wrinkle Timing ... 24 Guard Delay Time (GdLY) ...
  • Page 5 SECTION VII FACTORY PRESET PROGRAMS/PARAMETERS ... 51 A. Single Coin Only For all dryer models except AD-26/AD-295 and AD-540/WDA-540 ... 52 B. Dual Coin Only For all dryer models except AD-26/AD-295 and AD-540/WDA-540 ... 53 C. Single Coin Only For dryer models AD-26/AD-295 Only ... 54 D.
  • Page 6: Section I

    SECTION I INTRODUCTION The Phase 5 Coin Computer System is a fully programmable, highly sophisticated dryer control system. American Dryer Corporation has designed the Phase 5 coin microprocessor controller (computer) to be the most versatile and reliable coin-operated control system available. To eliminate as many moving parts as possible, ALL Phase 5 coin microprocessor controller (computer) programming is done through the membrane switch on the front of the control panel.
  • Page 7: Time For Amount To Start

    TIME FOR AMOUNT TO START This program retains the time the owner wishes to vend. The feature allows any additional purchase that is made to be calculated to the second. There is no calculation necessary by the owner. The Phase 5 coin microprocessor controller (computer) calculates the vended time.
  • Page 8 AUTOMATIC MODE (Patent No. 4,827,627) This program selection uses ADC’s patented Auto-Dry cycle. The microprocessor controller (computer) will calculate the percent of the dryness and read “donE” when complete. The Phase 5 coin microprocessor controller (computer) can be programmed to have a maximum time for the “Auto Mode.” The Automatic Cycle (mode) can be used in either the “Free Dry”...
  • Page 9: Temperature Display

    TEMPERATURE DISPLAY This program selection enables the temperature in the dryer to be viewed (°F or °C) either while the dryer is off or running. This service feature shows that the dryer is maintaining the selected temperature. DIAGNOSTICS ALL major circuits, including door, microprocessor temperature sensor, heat, and motor circuits are monitored. There are also indicators installed on the outputs of each relay to easily identify failures, and the door switch has an indicator installed on the Phase 5 microprocessor controller (computer) to help indicate failure.
  • Page 10: Display And Codes

    L.E.D. DISPLAY AND CODES ACOn Adrt AFAt AtIn AtSt AUtO bCLO bCrS CLCC Coin CrCC donE door dSFL FILL FrEE GdLY Gont * Refer to Phase 5 Coin System Diagnostics in Section VIII of this manual for detailed information. SECTION II Automatic Cycle (Slope Program Factor) Accumulative Coin Maximum Auto Dryness Time...
  • Page 11 HICd LCdE LOCd nbUZ nFLS nGrd nSEn PdrY PLOC PPCd PP°F PUSH rCdE SEFL tFAS tInE * Refer to Phase 5 Coin System Diagnostics in Section VIII of this manual for detailed information. Anti-Wrinkle Program Active High Cool Down Overheating Condition* Left Coin Count Left Coin Denomination Low Cool Down...
  • Page 12: Operating Instructions

    OPERATING INSTRUCTIONS NOTE: Unless otherwise specified at the time of ordering, the Phase 5 coin microprocessor controller (computer) has been preprogrammed by the factory with the parameters shown on page 52 and page 53 (for ALL dryer models except AD-26/AD-295 and AD-540/WDA-540) and page 54 and page 55 (for dryer models AD-26/AD-295 and AD-540/WDA-540 only).
  • Page 13: Automatic Mode (Patent No. 4,827,627)

    B. AUTOMATIC MODE (PATENT NO. 4,827,627) 1. When turning on power or when no cycle is in progress, the light emitting diode (L.E.D.) display will read “FILL” and/or “Amount To Start” (“AtSt”). 2. Insert coin(s). Once correct “Amount To Start” has been inserted, the L.E.D. display will read “PUSH.” 3.
  • Page 14: Free Dry Mode

    C. FREE DRY MODE When turning on power or when no cycle is in progress, the light emitting diode (L.E.D.) display will read “FILL” and/or “FrEE.” 2. Select temperature. The dryer will start, the L.E.D. display will read the temperature cycle selected and the drying time portion of the L.E.D.
  • Page 15: Program Selection

    NOTE: Programs are stored in the Phase 5 coin microprocessor controller (computer) memory and are cataloged as Program Locations (PL). TEMPERATURE DISPLAY MODE By closing the Program Switch (PS) located on the back side of the Phase 5 coin microprocessor controller (computer), the light emitting diode (L.E.D.) display will read the temperature in the dryer in either Fahrenheit (°F) or Celsius (°C), depending on how the temperature conversion status is in PL01.
  • Page 16: Automatic Review Of Program Location

    AUTOMATIC REVIEW OF PROGRAM LOCATION This selection allows for the AUTOMATIC REVIEW of what the program locations are set (programmed) for, thereby eliminating the need to go into each and every Program Location (PL) manually for verification. By closing the Programming Switch (PS) with no cycle in progress, the light emitting diode (L.E.D.) display will read the temperature in the dryer.
  • Page 17: Pl01 - Temperature Conversion Status

    PL01 - TEMPERATURE CONVERSION STATUS This program controls whether the temperature related programs will be operated in Fahrenheit (°F) or Celsius (°C). The programs affected are: 1. Temperature Display Mode 2. Selection Cycling Temperatures 3. Cool Down Temperatures AUTOMATIC MODE (AUtO) Patent No. 4,827,627 When this parameter (“AUtO”) is selected, the dryer will run for a preset level of dryness (PL02) or until the programmed automatic maximum time (PL14) has expired.
  • Page 18: Anti-Wrinkle Program (Grd)

    ANTI-WRINKLE PROGRAM (Grd) This feature can be used in conjunction with any of the three (3) operating modes (Coin Mode, Auto Mode, or the Free Dry Mode). In this program (“Grd”), when the drying and cooling cycles are completed, the dryer will shut off, the buzzer (tone) will sound, and the light emitting diode (L.E.D.) display will read “donE.”...
  • Page 19: Coin Mode (Coin)

    COIN MODE (COIN) In this program mode (“Coin”), coins are required to start the dryer, even if the Phase 5 coin microprocessor controller (computer) is set in the Automatic Mode (Patent No. 4,827,627). NOTE: When programming the use of the Coin Mode, (“Coin”), the following parameter/programs need to be checked and/or changed accordingly: PL01 ...
  • Page 20: Accumulative Time (Atin)

    ACCUMULATIVE TIME (AtIn) (SINGLE COIN) In this program mode (“AtIn”), each coin inserted has a specific value in time which is determined by the “Time For Amount To Start” (“tFAS”) program (PL11). Example No. 1: If the dryer is equipped with a 25¢ coin acceptor and the desired time is 30 minutes, each additional coin inserted would yield 30 minutes.
  • Page 21 Example No. 2: If the dryer is equipped with a 10¢/25¢ dual coin acceptor and the desired “Amount To Start” (“AtSt”) is 35¢ for 14 minutes, each additional 10¢ inserted would yield 4 minutes and each additional 25¢ would yield 10 minutes. Formula: (LCdE/AtSt) (tFAS) = Vended Time for “LCdE”...
  • Page 22: Accumulative Coin (Acon)

    ACCUMULATIVE COIN (ACOn) When this program mode (“ACOn”) is selected, additional time can only be achieved when the “Amount For Additional Time” (“AFAt”) PL13 has been inserted. NOTE: When programming, to use the Accumulative Coin Mode (“ACOn”), the following parameters/ programs need to be checked and/or changed accordingly: Settings: PL01 ...
  • Page 23: Rotational Safe Guard - Optional (Nsen)

    Formula: (AFAt/AtSt)(tFAS) = Vended Time for “AFAt” (25¢/35¢) (14 minutes) = 10 minutes Settings: PL09 (LCdE) ...10 ROTATIONAL SAFE GUARD - OPTIONAL (nSEn) This program monitors the rotation of the basket (tumbler) and works in conjunction with a special sensor (optional) located at the rear basket (tumbler) support area of the dryer.
  • Page 24: Pl04 - High Cool Down Temperature/Time (Hicd)

    PL04 - HIGH COOL DOWN TEMPERATURE/TIME (HICd) The first part of this program controls the cool down temperature when the Phase 5 microprocessor controller (computer) is used in the automatic mode. The cool down temperature is programmable from a minimum of 70°...
  • Page 25: Pl10 - Right Coin Slot Denomination (Rcde)

    PL10 - RIGHT COIN SLOT DENOMINATION (rCdE) This program need only be set when a dual coin acceptor is used. The program setting is determined by the value of the right coin acceptor slot (higher value). Program settings are from a minimum of 1 to a maximum of 9999. When used in conjunction with the Left Coin Slot Denomination program, the Phase 5 microprocessor controller (computer) automatically calculates the ratios necessary for coin insertion time values.
  • Page 26: Pl15 - Anti-Wrinkle Timing

    PL15 - ANTI-WRINKLE TIMING 1. Guard Delay Time (GdLY) This program controls the dwell (stop) time and activation of anti-wrinkle “Guard On Time” (“Gont”). The dwell (stop) time can be programmed from a minimum of 1 minute to a maximum of 9 minutes in 1 minute increments.
  • Page 27: Programming Instructions

    PROGRAMMING INSTRUCTIONS A. INTRODUCTION TO PROGRAMMING The various program (parameters) dryer selections are stored in the computer memory and are cataloged as “Program Locations” (PL) 1 through 17. These programs (parameters) have been preprogrammed by the factory as noted on page 52 and page 53 (for ALL models except AD-26/AD-295 and AD-540/WDA-540) and page 54 and page 55 (for dryer models AD-26/AD-295 and AD-540/WDA-540 ONLY) of this manual.
  • Page 28: Programming (Flowcharts)

    If the change to be made is a numerical one (i.e., time or temperature), the operator must now press the “HI TEMP” key to increase the number value, or press the “LO TEMP” key to lower/increase the number value. Pressing the “PERM PRESS” key will store the change and advance to the next step (bit) or program location. NOTE: To accelerate increase/upward value, press and hold in “HI TEMP”...
  • Page 29 Dryer Off (Power On) Display Reads To enter temperature display Display Reads To enter program locations press the “Perm Press” keyboard (touch pad) selection button. Display Reads To advance to next program location press the “HI Temp” selection button. Display Reads To accelerate advance, press and hold in “HI Temp”...
  • Page 30 To accelerate press and hold in “LO Temp” selection button. Display reads program locations and will advance downward until “LO Temp” selection button is released. To enter a specific program location (i.e. PL01) push the “Perm Press” selection button. Display will read specific program location called up.
  • Page 31: Programming

    A. TEMPERATURE DISPLAY MODE FILL HI Temp SECTION VI PROGRAMMING and/or (Close Program Switch) Cycle In Progress HI°2°0 (Close Program Switch) 13°5°F (Open Basket [Tumbler] Door-Dryer Shuts Off) 135F (Close Door - Open Program Switch) LO Temp LO°2°0 (Amount To Start) (Dryer Temperature Display) (Temperature Selection/Time) (Dryer Temperature Display)
  • Page 32: Left Coin Count

    B. LEFT COIN COUNT (No Cycle in Progress) FILL To cancel coin count To cancel or delete left coin count, press HI Temp “HI Temp” key. Display will read CLCC “CLCC” (cancel left coin count). Perm Press Press “Perm Press” key and display will read “0000”...
  • Page 33: Right Coin Count

    C. RIGHT COIN COUNT FILL HI Temp HI Temp To cancel coin count To cancel or delete HI Temp right coin count, press “HI Temp” key. Display will read CrCC “CrCC (cancel right coin count). Press “Perm Press” Perm Press key and display will read “0000”...
  • Page 34: Program Location 01 (Pl01)

    D. PROGRAM LOCATION 01 (PL01) FILL °FAr LO Temp °CEL tInE LO Temp AUtO (No Cycle In Progress) and/or To enter program mode, close program switch. (Close Program Switch) (Dryer Temperature Display) Press “Perm Press” key. Display will read Perm Press “PL01,”...
  • Page 35 nGrd HI Temp LO Temp HI Temp LO Temp nbUZ Coin LO Temp HI Temp FrEE Continue Perm Press LO Temp Perm Press nbUZ LO Temp Perm Press FrEE LO Temp Coin Perm Press Continue Display will read anti-wrinkle (guard) program status. If no change, press “Perm Press”...
  • Page 36 nFLS LO Temp If no flash is selected, display will read “fixed display” status. I.E. “AtSt” amount to start dryer or “Free Dry Mode” or “FILL.” If no change, press “Perm Press” otherwise press “HI” or “LO” keys and then press “Perm Press”...
  • Page 37 AtIn LO Temp ACOn LO Temp nSEn Proceed to next location to be changed Display will read coin/time accumulation status. I.E. “AtIn” accumulative time or “ACOn” accumulative coin. If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then press “Perm Press” key. Display will read basket rotational sensor status.
  • Page 38: Program Location 02 (Pl02)

    E. PROGRAM LOCATION 02 (PL02) Percent dry from 90 to 100% Dryness level decrease LO Temp ("Hold In" to Accelerate) Proceed to next location to be changed Summary: The percentage of dryness is programmable from a minimum of 90% to a maximum of 100%. Refer to Section V for instructions on entering program locations.
  • Page 39: Program Location 03 (Pl03)

    F. PROGRAM LOCATION 03 (PL03) HI Temp Refer to Section V for instructions on entering program locations. Temperature Decrease LO Temp Automatically goes into PL04 Program without PL04 Display Summary: HI Temp is programmable from a minimum of 100° F to a maximum of 190° F in ten-degree increments or from a minimum of 38°...
  • Page 40: Program Location 04 (Pl04)

    G. PROGRAM LOCATION 04 (PL04) HI Temp cool down temperature/time Continued from F. Temperature Decrease LO Temp Time Decrease LO Temp Proceed to next location to be changed Summary: Cool down temperature is programmable from a minimum of 70° F to a maximum of 190° F in ten degree increments or from a minimum of 21°...
  • Page 41: Program Location 05 (Pl05)

    H. PROGRAM LOCATION 05 (PL05) LO Temp Temperature Decrease LO Temp Summary: LO Temp is programmable from a minimum of 100° F to a maximum of 190° F in ten-degree increments or from a minimum of 38° C to a maximum of 88° C in five-degree increments. For the AD-26 and AD-295 any three (3) of the selections (HI/LO/PP) are programmable from a minimum of 100°...
  • Page 42: Program Location 06 (Pl06)

    I. PROGRAM LOCATION 06 (PL06) LO Temp cool down temperature/time Temperature Decrease LO Temp Time Decrease LO Temp Proceed to next location to be changed Summary: Cool down temperature is programmable from a minimum of 70° F to a maximum of 190° F in ten degree increments or from a minimum 21°...
  • Page 43: Program Location 07 (Pl07)

    J. PROGRAM LOCATION 07 (PL07) Perm Press Temp Temperature Decrease LO Temp Automatically goes into PL08 Program without PL08 Display Mode Summary: Perm Press Temp is programmable from a minimum of 100° F to a maximum of 190° F in ten-degree increments or from a minimum of 38°...
  • Page 44: Program Location 08 (Pl08)

    K. PROGRAM LOCATION 08 (PL08) Perm Press Cool Down Temperature/Time Continued from J. Temperature Decrease LO Temp Time Decrease LO Temp Proceed to next location to be changed Summary: Cool down temperature is programmable from a minimum of 70° F to a maximum of 190° F in ten-degree increments or from a minimum 21°...
  • Page 45: Program Location 09 (Pl09)

    L. PROGRAM LOCATION 09 (PL09) Left Coin Denomination Refer to Section V for instructions Amount Decrease LO Temp ("Hold In" to Accelerate) Proceed to next location to be changed Summary: The left coin denomination is programmable from 1 to 9999. IMPORTANT: When the dryer is equipped with a dual coin acceptor, the value set here is the lower value denomination, which is not necessarily the left coin portion of the acceptor.
  • Page 46: Program Location 10 (Pl10)

    M. PROGRAM LOCATION 10 (PL10) Right Coin Denomination Refer to Section V for instructions Amount Decrease LO Temp ("Hold In" to Accelerate) Proceed to next location to be changed Summary: The right coin denomination is programmable from 1 to 9999. IMPORTANT: When the dryer is equipped with a dual coin acceptor, the value set here is the higher value denomination, which is not necessarily the right coin portion of the acceptor.
  • Page 47: Program Location 11 (Pl11)

    N. PROGRAM LOCATION 11 (PL11) Time For Amount To Start Time Decrease LO Temp ("Hold In" to Accelerate) Proceed to next location to be changed Summary: The time for amount to start is programmable from 1 to 99 minutes. Refer to Section V for instructions on entering program locations.
  • Page 48: Program Location 12 (Pl12)

    O. PROGRAM LOCATION 12 (PL12) Amount To Start Amount Decrease LO Temp ("Hold In" to Accelerate) Proceed to next location to be changed Summary: The amount to start is programmable from 1 to 9999. Refer to Section V for instructions on entering program locations.
  • Page 49: Program Location 13 (Pl13)

    P. PROGRAM LOCATION 13 (PL13) Coin Accumulation Minimum Amount for More Time Refer to Section V for instructions on entering program locations. Amount Decrease LO Temp ("Hold In" to Accelerate) Proceed to next location to be changed Summary: The amount to start is programmable from 1 to 9999. Location to be viewed/changed.
  • Page 50: Program Location 14 (Pl14)

    Q. PROGRAM LOCATION 14 (PL14) Maximum Time for Auto Dry Time Decrease LO Temp ("Hold In" to Accelerate) Proceed to next location to be changed Summary: The maximum auto dryness time is programmable from 1 to 99 minutes. Refer to Section V for instructions on entering program locations.
  • Page 51: Program Location 15 (Pl15)

    R. PROGRAM LOCATION 15 (PL15) Anti-Wrinkle Timing Refer to Section V for instructions Time Decrease LO Temp ("Hold In" to Accelerate) Time Decrease LO Temp ("Hold In" to Accelerate) Proceed to next location to be changed Summary: Guard delay time is programmable from 1 to 9 minutes. Guard on time is programmable from 1 to 99-seconds.
  • Page 52: Program Location 16 (Pl16) And Program Location 17 (Pl17)

    S. PROGRAM LOCATION 16 (PL16) AND PROGRAM LOCATION 17 (PL17) Maximum Active Anti-Wrinkle Time Refer to Section V for instructions on entering program locations. Time Decrease LO Temp ("Hold In" to Accelerate) Refer to Section V for instructions on entering program locations. Programmable 1 to 9 Factor Decrease LO Temp...
  • Page 53: Factory Preset Programs/Parameters

    SECTION VII FACTORY PRESET PROGRAMS/PARAMETERS Unless otherwise specified at the time of ordering, the Phase 5 microprocessor controller (computer) has been preprogrammed by the factory with the following programs/parameters. Should changes be found necessary, please read this Phase 5 Coin User’s Manual carefully to thoroughly familiarize yourself with the Phase 5 microprocessor controller’s (computer’s) programming characteristics.
  • Page 54: Single Coin Only

    A. SINGLE COIN ONLY For ALL dryer models except AD-26/AD-295 and AD-540/WDA-540. (For Single Coin models AD-26/ AD-295 and AD-540/WDA-540 refer to page 54). PL01 - °FAr - Temperatures in Fahrenheit tInE - Timed mode - Anti-wrinkle guard on - Anti-wrinkle guard buzzer (tone) on Coin - Coin(s) required to start - Display will flash in intervals between “FILL”...
  • Page 55: Dual Coin Only

    B. DUAL COIN ONLY For ALL dryer models except AD-26/AD-295 and AD-540/WDA-540. (For Dual Coin models AD-26/ AD-295 and AD-540/WDA-540 refer to page 55). PL01 - °FAr - Temperatures in Fahrenheit tInE - Timed mode - Anti-wrinkle guard on - Anti-wrinkle guard buzzer (tone) on Coin - Coin(s) required to start - Display will flash in intervals between “FILL”...
  • Page 56: Single Coin Only

    C. SINGLE COIN ONLY For dryer models AD-26/AD-295 and AD-540/WDA-540 ONLY PL01 - °FAr - Temperatures in Fahrenheit tInE - Timed mode - Anti-wrinkle guard on - Anti-wrinkle guard buzzer (tone) on Coin - Coin(s) required to start - Display will flash in intervals between “FILL” and “Amount To Start” bCrS - Bad coin reset AtIn...
  • Page 57: Dual Coin Only

    D. DUAL COIN ONLY For dryer models AD-26/AD-295 and AD-540/WDA-540 ONLY PL01 - °FAr - Temperatures in Fahrenheit tInE - Timed mode - Anti-wrinkle guard on - Anti-wrinkle guard buzzer (tone) on Coin - Coin(s) required to start - Display will flash in intervals between “FILL” and “Amount To Start” bCrS - Bad coin reset AtIn...
  • Page 58: Phase 5 Coin System Diagnostics

    PHASE 5 COIN SYSTEM DIAGNOSTICS ALL major circuits, including door, microprocessor temperature sensor, heat and motor circuits are monitored. The Phase 5 coin microprocessor controller (computer) will inform the user via the light emitting diode (L.E.D.) display of certain failure codes along with indicators both in the L.E.D. display and at the outputs of each relay (and door switch circuit) to easily identify failures.
  • Page 59: Sefl

    3. “SEFL” - Indicates rotational sensor circuit failure meaning that there is a fault somewhere in the basket (tumbler) rotation detection circuit or the microprocessor controller (computer) program related to this circuit (PL01) is set incorrectly in the active mode (“SEn”), where the dryer is not equipped with optional rotation sensor and should be set in the inactive mode (“nSEn”).
  • Page 60: Phase 5 Microprocessor Controller (Computer) Relay Output L.e.d. Indicators

    C. PHASE 5 MICROPROCESSOR CONTROLLER (COMPUTER) RELAY OUTPUT LIGHT EMITTING DIODE (L.E.D.) INDICATORS There are three (3) L.E.D. indicators (“red” lights) located at the lower back side area of the microprocessor controller (computer) which are identified/labeled as “DOOR,” “HEAT,” and “MTR” (motor). These L.E.D.s indicate that the outputs of the microprocessor controller (computer), or in the case of the door switch, the inputs are functioning.
  • Page 61: Heat

    NOTE: If the failure was elsewhere (i.e. dryer’s door switch circuit) the light emitting diode (L.E.D.) display would read “door” if a keyboard (touch pad) entry was attempted. If the display L.E.D. indicators are on, and the door L.E.D. indicators are on, and the door L.E.D. input and motor/heat output L.E.D.s are on, yet the motor and/or heat is not active (on);...
  • Page 62: Phase 5 Auto Cycle (Patent No. 4,827,267) "A" And "B" Factor Parameters

    PHASE 5 AUTO CYCLE (PATENT NO. 4,827,627) Model "A" "b" ADG-15D ADG-25D ADG-26D N/A* ADG-215D ADG-220D ADG-230D ADG-320D ADG-330D ADG-285DH ADG-295D N/A* ADG-30DS (A) ADG-30DS (b) N/A* ADG-30D ADG-50D UDG-50D ADG-75D * “A” and “b” Factors N/A at time of printing. NOTE: For letter designations refer to the following page (page 61).
  • Page 63 (A) For 60 Hz models ONLY (B) For 50 Hz models ONLY IMPORTANT: The “A” and “b” Factors have been preprogrammed by the factory and should be changed in the field unless the Phase 5 coin microprocessor controller (computer) should fail and is replaced. THE REPLACEMENT PHASE 5 COIN MICROPROCESSOR CONTROLLER (COMPUTER) MUST BE REPROGRAMMED FOR THE SPECIFIC MODEL SHOWN IN THE CHART ON THE PREVIOUS PAGE (page 60).
  • Page 64: Optional 9 Volt Battery Backup

    SECTION X OPTIONAL 9 VOLT BATTERY BACKUP Dryers ordered from the factory with the 9 volt battery backup option (battery is not included) allow the Phase 5 microprocessor controller (computer) to maintain its operating status should a momentary power interruption occur while the dryer cycle is in progress.
  • Page 65 Notes _____________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________...
  • Page 66 ADC Part No. 112146 56 - 10/28/08 - 1...
