Direct Spark Ignition (DSI) Burner Assembly

For Models Mfd. prior to April 15, 2000

Illus. No.
Part No.
5
150300
6
140819**
140803**
7
150103
8
153000
9
151001
10
128927
880960
140411
11
318712
12
150309
13
881367
14
142809
15
810030
16
128935
17
809309
18
150309
19
319704
20
151001
21
150001
22
130201
23
318700
24
143000
25
154004
26
150309
27
802799
28
122200
881706
29
150303
30
105500
31
319202
32
154002
*
Burner orifices are not included and must be ordered separately.
**
Consult factory for elevations over 2,000 feet.
Telephone: (508) 678-9000
Qty.
Description
2
#10-16 x 1/2" Hex Washer TEK Screw
4
#30 Burner Orifice (natural gas)
4
#49 Burner Orifice (liquid propane [L.P.] gas)
4
#8-32 x 1/2" Phillips Round Head Machine Screw
4
#8 Steel Burr
4
#8-32 Pal Nut
1
1/2" 24 VAC Redundant (natural gas) Gas Valve
1
1/2" 24 VAC Liquid Propane (L.P.) Gas Valve Assembly
1
24 VAC Gas Valve Liquid Propane (L.P.) Conversion Kit
1
Pipe Bracket
7
#10-16 x 1/2" Hex Head TEK Crimptite Screw
1
1/2" Union Shutoff with Tail Piece
1
1/2" x 29-1/8" Nipple
1
Direct Spark Ignition (DSI) Module Mounting Bracket
1
Direct Spark Ignition (DSI) Module with 3 Tries
1
Ignitor Assembly with High Voltage (HV) Wire
3
#10-16 x 1/2" Hex Head TEK Crimptite Screw
1
Hi-Limit Mounting Bracket
2
#8-32 Pal Nut
2
#6-32 x 1/2" Phillips Round Head Machine Screw
1
330º F Manual Reset Hi-Limit
1
Pipe Bracket
1
3/4" to 1/2" Reducing Coupling
1
Twin Speed Nut
2
#10-16 x 1/2" Hex Head TEK Crimptite Screw
1
Sail Switch Cover and Bracket
1
Sail Switch ONLY
1
Sail Switch Box Assembly Complete
(includes illus. nos. 26 through 32)
2
#4 x 3/4" Pan Head "A" Machine Screw
1
Sail Switch Actuator Rod
1
Sail Switch Damper (flat)
1
1/8" Push On Fastener
(continued)
Fax: (508) 678-9447
33
