AD-25V Installation Manual
Phase 5 / 8-Inch Exhaust Duct / Dual Timer
WARNING: For your safety the
information in this manual must be
followed to minimize the risk of fire or
explosion and to prevent property
damage, personal injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Clear the room, building or area of all
occupants.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
AVERTISSEMENT: Assurez-vous de
bien suivre les instructions données dans
cette notice pour réduire au minimum le
risque d'incendie ou d'explosion ou pour
éviter tout dommage matériel, toute
blessure ou la mort.
— Ne pas entreposer ni utiliser d'essence
ni d'autres vapeurs ou liquides
inflammables à proximité de cet appareil
ou de tout autre appareil.
— QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
• Ne pas tenter d'allumer d'appareils.
• Ne touchez à aucun interrupteur. Ne
pas vous servir des téléphones se
trouvant dans le bâtiment.
• Évacuez la pièce, le bâtiment ou la zone.
• Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
— L'installation et l'entretien doivent être
assurés par un installateur ou un service
d'entretien qualifié ou par le fournisseur
de gaz.
American Dryer Corporation
88 Currant Road
Fall River MA 02720-4781 USA
Telephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447
e-mail: techsupport@amdry.com
www.adclaundry.com
ADC Part No. 113329 - 13

Advertisement

Table of Contents
loading

Related Manuals for ADC AD-25V

Summary of Contents for ADC AD-25V

  • Page 1 American Dryer Corporation 88 Currant Road Fall River MA 02720-4781 USA Telephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447 e-mail: techsupport@amdry.com www.adclaundry.com ADC Part No. 113329 - 13...
  • Page 2 We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models.

  • Page 3: Table Of Contents

    WARNING In the State of Massachusetts, the following installation instructions apply: Proposition 65 ■ Installations and repairs must be performed by a Use of this product could expose you to substances qualified or licensed contractor, plumber, or gasfitter qualified or licensed by the State of Massachusetts. from fuel combustion that contain chemicals ■...

  • Page 4: Important Information

    It is your responsibility to file freight claims. Dryer/parts damaged in transit cannot be claimed under warranty. 5. Freight claims are the responsibility of the consignee, and ALL claims must be filed at the receiving end. ADC assumes no responsibility for freight claims or damages.

  • Page 5: Safety Precautions

    5. Installation and service must be performed by a qualified installer, service agency, or gas supplier. 6. Dryer(s) must be exhausted to the outdoors. 7. Although ADC produces a very versatile dryer, there are some articles that, due to fabric composition or cleaning method, should not be dried in it.
  • Page 6 8. The possible presence of residual quantities of aggressive or decomposed chemicals in the load may produce damage to the machine and harmful fumes. 9. A program should be established for the inspection and cleaning of lint in the burner area, exhaust ductwork, and area around the back of the dryer.

  • Page 7: Specifications

    *** Specify air-operated or electromechanical steam damper system. Air-operated steam damper system must be provided with clean, dry, and regulated 80 psi ± 10 psi (5.51 bar ± 0.68 bar) air supply. NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation.
  • Page 8 Specifications NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation. American Dryer Corp. 113329 - 13...

  • Page 9: Installation Procedures

    SECTION III INSTALLATION PROCEDURES Installation should be performed by competent technicians in accordance with local and state codes. In the absence of these codes, the installation must conform to applicable American National Standards: ANSI Z223.1-LATEST EDITION (National Fuel Gas Code) or ANSI/NFPA NO. 70-LATEST EDITION (National Electrical Code) or in Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P.

  • Page 10: Location Requirements

    B. LOCATION REQUIREMENTS Before installing the dryer, be sure the location conforms to local codes and ordinances. In the absence of such codes or ordinances the location must conform with the National Fuel Gas Code ANSI.Z223.1 LATEST EDITION, or in Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P.

  • Page 11: Dryer Enclosure Requirements

    C. DRYER ENCLOSURE REQUIREMENTS Bulkheads and partitions should be made of noncombustible materials and must be located a minimum of 12-inches (30.48 cm) above the dryer’s outer top; 18-inches (45.72 cm) for steam dryers, except along the front of the dryer which may be closed if desired.

  • Page 12: Fresh Air Supply Requirements

    D. FRESH AIR SUPPLY REQUIREMENTS This appliance may only be installed in a room that meets the appropriate ventilation requirements specified in the national installation regulations. The air supply (make-up air) must be given careful consideration to assure proper performance of each dryer. An unrestricted source of air is necessary for each dryer.

  • Page 13: Exhaust Requirements

    E. EXHAUST REQUIREMENTS Exhaust ductwork should be designed and installed by a qualified professional. Improperly sized ductwork will create excessive back pressure, which results in slow drying, increased use of energy, and shutdown of the burner by the airflow (sail) switch, burner hi-limit, or lint chamber hi-heat protector thermostat. The dryer must be installed with a proper exhaust duct connection to the outside.
  • Page 14 SINGLE DRYER VENTING IMPORTANT: For exhaust duct runs over 25 feet (7.62 meters) a minimum size of 10-inches (25.4 cm) must be used. HORIZONTAL VENTING When a single 8-inch (20.32 cm) horizontal vent is used, the ductwork to the outlet cannot exceed 25 feet (7.62 meters) refer to Illus.
  • Page 15 VERTICAL VENTING When vertical single 10-inch (25.4 cm) venting is used (refer to Illus. B below), the ductwork from the dryer to the outside outlet cannot exceed 40 feet (12.19 meters) (refer to Illus. B below). This calculation compensates for the use of a maximum of three (3) elbows including the two (2) elbows creating the 180°...
  • Page 16 MULTIPLE DRYER (COMMON) VENTING If it is not feasible to provide separate exhaust ducts for each dryer, ducts for individual dryers may be channeled into a common main duct. Each dryer is provided with a back draft damper. The individual ducts should enter the bottom or side of the main duct at an angle not more than 45°...
  • Page 17 HORIZONTAL VENTING Illus. C VERTICAL VENTING Illus. D 113329 - 13 www.adclaundry.com...

  • Page 18: Electrical Information

    F. ELECTRICAL INFORMATION 1. Electrical Requirements It is your responsibility to have ALL electrical connections made by a properly licensed and competent electrician to assure that the electrical installation is adequate and conforms to local and state regulations or codes. In the absence of such codes, ALL electrical connections, materials, and workmanship must conform to the applicable requirements of the National Electrical Code ANSI/NFPA NO.
  • Page 19 2) Electric Models ONLY ALL electrically heated dryers must be connected to the electric service shown on the dryer’s data label, which is affixed to either the backside of the upper control door or left side panel/wall area behind the control door. The connecting wires must be properly sized to handle the rated current. NOTE: Electrically heated service (amperage) specifications/requirements are not available at the time of printing.
  • Page 20 INGLE HASE Ø LECTRICAL ONNECTIONS EADS Black White Green White Neutral Ground If local codes permit, power to the dryer can be made by the use of a flexible UL listed power cord or pigtail (wire size must conform to rating of dryer), or the dryer can be hard wired directly to the service breaker panel.
  • Page 21 5. 3-Phase (3ø) Wiring Connections / Hookup The only electrical input connections to the dryer are the 3-phase (3ø) power leads (L1, L2, L3, and sometimes Neutral) and ground. Single-phase (1ø) power for the control circuit is done internally to the dryer. No single- phase (1ø) input connection is required on a 3-phase (3ø) dryer.
  • Page 22 CAUTION: The dryer must be grounded. A ground lug has been provided for this purpose. IMPORTANT: A CIRCUIT SERVICING EACH DRYER MUST BE PROVIDED. The only electrical connections to the dryer are the 3-phase (3ø) leads (L1, L2, L3, and sometimes Neutral) and ground.
  • Page 23 WARNING: 208 VAC AND 240 VAC ARE NOT THE SAME. Any damage done to dryer components due to improper voltage connections will automatically VOID THE WARRANTY. NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation. 113329 - 13...

  • Page 24: Gas Information

    (access) door. If this information does not agree with the type of gas available, DO NOT operate the dryer. Contact the reseller who sold the dryer or contact the ADC factory. IMPORTANT: Any burner changes or conversions must be made by a qualified professional.
  • Page 25 2. Technical Gas Data a. Gas Specifications For Australia, refer to data plate. TYPE OF GAS NATURAL LIQUID PROPANE 8.7 mb 26.1 mb Manifold Pressure* 3.5 inches W.C. 10.5 inches W.C. 6.0 - 12.0 inches W.C. 14.92 - 29.9 mb 27.4 mb In-Line Pressure 11.0 inches W.C.
  • Page 26 3. Piping Connections ALL components/materials must conform to National Fuel Gas Code Specifications ANSI Z223.1-LATEST EDITION, or in Canada, CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P. Gas) or LATEST EDITION (for General Installation and Gas Plumbing), as well as local codes and ordinances and must be done by a qualified professional.
  • Page 27 NOTE: Undersized gas supply piping can create a low or inconsistent pressure, which will result in erratic operation of the burner ignition system. Consistent gas pressure is essential at ALL gas connections. It is recommended that a 3/4-inch (19.05 mm) pipe gas loop be installed in the supply line servicing a bank of dryers.

  • Page 28: Steam Information

    H. STEAM INFORMATION It is your responsibility to have ALL plumbing connections made by a qualified professional to assure that the steam plumbing installation is adequate and conforms with local and state regulations or codes. Care must be exercised when leveling steam dryers into final position. After leveling the dryer, check the downward pitch of the heat exchanger from front to rear with a level.
  • Page 29 a. The presence of condensate in the steam supply will cause water hammer and subsequent heat exchanger (steam coil) failure. The steam supply connection into the main supply line must be made with a minimum 10-inch (25.4 cm) riser. This will prevent any condensate from draining towards the dryer. b.
  • Page 30 4. Steam Damper Air System Connections The dryer is manufactured with a pneumatic (piston) damper system, which requires an external supply of compressed air. The air connection is made to the steam damper solenoid valve, which is located at the rear inner top area of the dryer just in front of the electric service relay box.
  • Page 31 5. Steam Damper System Operation The steam damper, as shown in the illustration below, allows the coil to stay constantly charged eliminating repeated expansion and contraction. When the damper is opened, the air immediately passes through the already hot coil, providing instant heat to start the drying process. When the damper is closed, ambient air is drawn directly into the tumbler, allowing a rapid cool down.
  • Page 32 6. Steam Damper Air Piston (Flow Control) Operation Adjustment Damper operation was tested and adjusted prior to shipping at 80 PSI (5.51 bar). If damper air adjustment is necessary, locate the flow control valve and make the necessary adjustments as noted below. American Dryer Corp.

  • Page 33: Preparation For Operation / Start-Up

    I. PREPARATION FOR OPERATION / START-UP The following items should be checked before attempting to operate the dryer: 1. Read ALL “CAUTION,” “WARNING,” and “DIRECTION” labels attached to the dryer. 2. Check incoming supply voltage to be sure that it is the same as indicated on the dryer data label affixed to the left side panel area behind top control (access) door.

  • Page 34: Preoperational Test

    J. PREOPERATIONAL TEST ALL dryers are thoroughly tested and inspected before leaving the factory. However, a preoperational test should be performed before the dryer is publicly used. It is possible that adjustments have changed in transit or due to marginal location (installation) conditions. Installer must instruct the user on how to correctly operate the dryer before leaving.

  • Page 35: Preoperational Instructions

    NOTE: The sail switch can be checked for proper operation by opening the lint drawer. While pushing the lint drawer switch in, start a drying cycle. The heating unit should not activate (wait 30-seconds). If heat does activate, make the necessary adjustments to the sail switch. 5.
  • Page 36 d. Once the preprogrammed dryness level and cool down period have been reached, or the maximum automatic time has expired, the tone (buzzer) will sound for 5-seconds, and the L.E.D. display will read “donE,” at which time the dryer will shut off. NOTES: 1.
  • Page 37 b. Select Temperature... The dryer will start, the L.E.D. display will read the temperature cycle selected, and the drying time portion of the L.E.D. display will read “00” and count upward as time elapses, or the vended time will count downward, depending on the program parameter setting.

  • Page 38: Shutdown Instructions

    OPL MODELS 1. To start the dryer: a. Microprocessor Controller (Computer) Dryers... 1) The L.E.D. display will read “FILL.” 2) Press the “E” on the keypad. 3) The L.E.D. display will quickly show “Ld30,” “LC04,” and “F180.” The dryer will start, and the L.E.D.

  • Page 39: Service / Parts Information

    1. Replacement parts should be purchased from the reseller from whom the ADC equipment was purchased. If the reseller cannot be contacted or is unknown, contact the ADC Parts Department for a reseller in your area. Parts may also be purchased directly from the factory by calling the ADC Parts Department at (508) 678-9000 or you may FAX in your order at (508) 678-9447.

  • Page 40: Warranty Information

    A. RETURNING WARRANTY CARDS 1. Before any dryer leaves the ADC factory test area, a warranty card is placed on the back side of the main door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you should you file a warranty claim.
  • Page 41 IMPORTANT: No replacements, credits, or refunds will be issued for merchandise damaged in transit. 5. ALL returns should be shipped to the ADC factory in such a manner that they are insured and a proof of delivery can be obtained by the sender.

  • Page 42: Routine Maintenance

    Maximum operating efficiency is dependent upon proper air circulation. The accumulation of lint can restrict this airflow. If the guidelines in this section are met, an ADC dryer will provide many years of efficient, trouble free, and most importantly safe operation.

  • Page 43: Adjustments

    Provisions are made in the bearing housing for the addition of a grease fitting, which can be obtained elsewhere, or from ADC by ordering kit Part No. 882159 (includes two [2] fittings).

  • Page 44: Lint Drawer Removal

    D. LINT DRAWER REMOVAL To remove the lint drawer from the dryer pull drawer out approximately halfway. Rotate/move lint drawer stop hinge (refer to the illustration below) downward and pull the drawer out. IMPORTANT: After replacing the lint drawer back into the dryer, be sure to rotate/move hinge back to the upward stop position.

  • Page 45: Troubleshooting

    SECTION VII TROUBLESHOOTING IMPORTANT: YOU MUST DISCONNECT AND LOCKOUT THE ELECTRIC SUPPLY AND THE GAS SUPPLY OR THE STEAM SUPPLY BEFORE ANY COVERS OR GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, OR TESTING OF ANY EQUIPMENT PER OSHA STANDARDS.
  • Page 46 D. Drive motor operates okay for a few minutes and then stops and will not restart... 1. Motor is overheating and tripping out on internal overload protector... a. Motor air vents clogged with lint. b. Low voltage to the motor. c.
  • Page 47 Microprocessor controller (computer) display reads “door”... 1. Fault (open circuit) in door switch circuit... a. Failed main door switch. b. Broken connection/wire in main door circuit. 2. Failed 24 VAC transformer. K. Microprocessor controller (computer) will not accept any keypad entries, i.e., L.E.D. display reads “FILL”...
  • Page 48 1) Lint screen is dirty. 2) Restriction in exhaust ductwork. 2. Fault in burner hi-limit circuit or tripped manual reset hi-limit. 3. Fault in lint chamber sensor bracket or tripped manual reset hi-heat (limit) protector thermostat. 4. Failed DSI module. 5.
  • Page 49 10. Failed microprocessor temperature sensor...calibration is inaccurate. 11. Steam damper system is not functioning properly (for STEAM MODELS ONLY)... a. Damper sticking closed. b. Leak in pneumatic (air) system. 12. Failed electric oven element(s) (for ELECTRIC MODELS ONLY). R. Condensation on main door glass... 1.
  • Page 50 DUAL TIMER MODELS A. Dryer will not start...both drive motor and blower motor are not operating (indicator light is off)... 1. Dryer control circuit fuse is blown. 2. Open at location...service main fuse or circuit breaker. 3. Failed push to start relay. 4.
  • Page 51 ELECTRIC MODELS ONLY 1. Fault in sail switch circuit... a. Sail switch is out of adjustment and/or failed. b. Sail switch is not closing or fluttering... 1) Check blower (squirrel cage fan) motor and rotation direction. 2) Restriction in location exhaust system. 2.
  • Page 52 Dryer is cycling on or tripping hi-limit thermostat (for GAS AND ELECTRIC MODELS ONLY)... 1. Blower (squirrel cage fan) motor failure. 2. Blower (squirrel cage fan) motor rotation direction is incorrect. 3. Insufficient make-up air. 4. Restriction in location exhaust system... a.

  • Page 53: Data Label Information

    When contacting American Dryer Corporation, certain information is required to ensure proper service/parts information from ADC. This information is on the data label located on the left side panel area behind top control (access) door. When contacting ADC, please have the AGA Label model number and serial number available.

  • Page 54: Reversing Timer Spin / Dwell Adjustments

    SECTION IX REVERSING TIMER SPIN / DWELL ADJUSTMENTS Dual timer models with “reversing option” have an electric reversing timer in the electric service box, which is located in the upper rear area of the dryer. Both the dwell (stop) time and tumbler spin time are adjustable by mode selection switches located on the electronic timer (as noted in the illustration below).

  • Page 55: Procedure For Functional Check Of Replacement Components

    SECTION X PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT COMPONENTS 1. Microprocessor Controller (Computer) Board a. Upon completing installation of the replacement microprocessor controller (computer) board, reestablish power to the dryer. b. Start the drying cycle. c. Verify that the motor(s) and the heat indicator dots, in the microprocessor controller (computer) L.E.D. display are on.
  • Page 56 e. Open main door. The dryer must stop and ALL output indicator lights on the back side of the microprocessor controller (computer) board must go out. (Refer to the illustration on the previous page.) f. Try to restart the dryer with the main door open. g.
  • Page 57 3. For DSI System Models Manufactured With ADC Module Part No. 882627 a. Upon completing installation of the replacement DSI module, reestablish power to the dryer. b. Starting the drying cycle. c. The ignition DSI module’s L.E.D. indicator will light “red” for up to approximately 1.5-seconds (prepurge time).

  • Page 58: Burner And Tumbler / Lint Chamber

    The location of the manual reset hi-limit switch is on the right side of the burner box. IMPORTANT This dryer is equipped with a burner hi-limit and tumbler/lint chamber hi-limit thermostat which must be reset manually. WARNING: Discontinue power to dryer before attempting to reset hi-limit. ADC P/N: 114093 American Dryer Corp. 113329 - 13...
  • Page 59 WARNING: Discontinue power to dryer before attempting to reset hi-limit. IMPORTANT This dryer is equipped with a lint chamber hi-limit thermostat which must be reset manually. WARNING: Discontinue power to dryer before attempting to reset hi-limit. ADC P/N: 114501 113329 - 13 www.adclaundry.com...
  • Page 60 ADC Part No. 113329 13 - 05/01/17...
