Non-Reversing T.E.F.C. Motor Mount Assembly

Illus. No. Part No.
1 100117
2 100701
3 101133
101130
4 150501
5 153002
6 153001
7 100069*
181016
8 122701
122801
9 137030
10 152004
11 153002
12 153001
13 117604
14 154000
15 850018
804019*
882492
16 153051
17 100603
18 100714
19 153050
20 152006
21 120200
22 100007
* Specify voltage when ordering.
** Contact factory for information.
Telephone: (508) 678-9000
Qty. Description
1 4L-620 V-Belt (motor to idler)
1 3/16" x 3/16" x 1" Key
1 5/8" x 2-1/4" Motor Pulley (for 60 Hz models Only)
1 5/8" x 2-1/2" Motor Pulley (for 50 Hz models Only)
4 5/16-18 x 3/4" Hex Head Machine Bolt
4 5/16" Lock Washer
4 5/16" Flat Washer
1 3/4 HP 120/208/230v 1ø Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor
with Plug (56Z frame) for 60 Hz Models ONLY
1 3/4 HP 230v 1ø (with 3/4" shaft) Totally Enclosed, Fan-Cooled (T.E.F.C.)
Motor with Plug (56Z frame) for 50 Hz Models ONLY
8 Socket Terminal ONLY
1 Pin/Socket Extraction Tool
1 8-Pin Housing Connector
4 5/16-18 Hex Nut
4 5/16" Lock Washer
4 5/16" Flat Washer
4 Neoprene Sponge Tape (sold by the foot)
4 5/16-18 Tinnerman Nut
1 Non-Reversing Motor Mount ONLY (56Z frame)
1 3/4 HP 120/230v 1ø Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount
Assembly with Plug Complete for 60 Hz Models ONLY
(includes illus. nos. 2 through 7 and 13 through 20)
** 3/4 HP 230v 1ø Non-Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.)
Motor Mount Assembly Complete for 50 Hz Models ONLY
(includes illus. nos. 2 through 6 and 13 through 22)
1 3/4" S.A.E. Flat Washer
1 16" Impellor with 3/4" Bore (for 50 Hz models Only)
1 3/16" x 3/16" x 1-7/8" Key
2 1/2" S.A.E. Flat Washer
2 1/2-20 Left Hand Jam Nut
1 3/8" x 90° Connector
1 1/2 HP 208/460v 50/60 Hz Motor (for 3-phase [3ø] models Only)
