ADC ADG-758 Parts Manual

Adc gas dryer parts manual
Hide thumbs Also See for ADG-758:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
ADG-758
(Gas - DSI)
Parts Manual
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
e-mail: techsupport@amdry.com
www.amdry.com
081999MFM/abe
ADC Part No. 450419

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADG-758 and is the answer not in the manual?

Questions and answers

Related Manuals for ADC ADG-758

Summary of Contents for ADC ADG-758

  • Page 1 ADG-758 (Gas - DSI) Parts Manual American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 e-mail: techsupport@amdry.com www.amdry.com 081999MFM/abe ADC Part No. 450419...
  • Page 2 We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models.

  • Page 3: Table Of Contents

    Control Door Assembly Without Trim ... 2 Control Door Assembly With Trim ... 3 Phase 5 OPL Microprocessor Control Panel Assembly ... 4 Phase 5 Coin Microprocessor Control Panel Assembly ... 5 Phase 5 Coin and OPL Microprocessor Control Box Assembly ... 6 Coin Vault Assembly ...

  • Page 4: Control Door Assembly Without Trim

    Illus. No. Part No. Qty. Description 881053 ADC Logo ONLY 870011 Logo Double Adhesive Tape Kit ONLY 881045* Control Door (includes illus. nos. 2, 3, and 8) 881046 Stainless Steel Control Door (includes illus. nos. 2, 3, and 8) 117604...

  • Page 5: Control Door Assembly With Trim

    160017 Special Dummy Lock (for non-coin models Only) 160104 MK-100 Key 160016 Lock Cam 881053 ADC Logo 870011 Logo Double Tape Kit 800020* High Security Control Door Assembly (includes illus. nos. 4 through 7) 800144 Stainless Steel High Security Control Door Assembly (includes illus.

  • Page 6: Phase 5 Opl Microprocessor Control Panel Assembly

    Phase 5 OPL Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112535 OPL English Keyboard Label Assembly 112276 OPL Stick-On Labels (English Only)...Not Illustrated 112275 3-Language OPL Stick-On Labels...Not Illustrated (Spanish, Italian, and Hebrew) 112277 3-Language OPL Stick-On Labels...Not Illustrated (English, Spanish, and Hebrew) 112278 5-Language OPL Stick-On Labels...Not Illustrated...

  • Page 7: Phase 5 Coin Microprocessor Control Panel Assembly

    Phase 5 Coin Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112526 Coin Keyboard Label Assembly 801213 Phase 5 Coin Control Panel Assembly (includes illus. nos. 1, 2, and 4 through 6) 801229 Phase 5 Coin Control Panel Assembly with Battery Option (includes illus.

  • Page 8: Phase 5 Coin And Opl Microprocessor Control Box Assembly

    Phase 5 Coin and OPL Microprocessor Control Box Assembly Illus. No. Part No. Qty. Description 141403 Transformer - 24 VAC 150300 #10-16 x 1/2” Hex Washer TEK Screw 120715 30-Position Terminal Block 150002 #6-32 x 1” Phillips Round Head Machine Screw 151000 #6-32 Pal Nut 136057...

  • Page 9: Coin Vault Assembly

    Coin Vault Assembly Illus. No. Part No. Qty. Description 802112 Microprocessor Coin Vault Assembly Complete (includes illus. nos. 1 through 6) 802117 Microprocessor Coin Vault ONLY 160028 Cam for 1/4 Turn Lock 875061 1/4 Turn Lock with Key and Cam 160105* 1/4 Turn Mer-Pel Key ONLY 802020...

  • Page 10: Dual Timer "Tap Touch" Controls For Models Mfd. As Of November 3, 2000

    Illus. No. Part No. Qty. Description 124030 15 Minute Timer - 24 VAC 124025 60 Minute Timer - 24 VAC 824175 Red Pilot Light - 24 VAC 122301 “Tap Touch” Switch 131932 Relay SPST 24v 120730 30-Position Terminal Block 151000 #6-32 Pal Nut 882903 Dual Timer Panel Complete...

  • Page 11: Dual Timer Control Panel Assembly

    Dual Timer Control Panel Assembly For Models Mfd. prior to November 3, 2000 Illus. No. Part No. Qty. Description 123005 Red Indicator Light - 24 VAC 122400 Rocker Heat Selector Switch 824015 Dual Timer Control Panel Assembly Complete - 24 VAC (includes illus.

  • Page 12: Dual Timer Control Box Assembly

    Illus. No. Part No. Qty. Description 122603 9-Pin Socket Connector 122701 Socket Terminal 122801 Pin/Socket Extraction Tool 315010 9-Pin Connector Bracket 150300 #10-16 x 1/2” Hex Washer TEK Screw 150300 #10-16 x 1/2” Hex Washer TEK Screw 141403 Transformer - 24 VAC 136008 Fuse Block/Strip 136057...

  • Page 13: Front Panel Assembly For Plastic Door

    Front Panel Assembly for Plastic Door Illus. No. Part No. Qty. Description 875302* Right Hand Insulated Front Panel Assembly Complete (includes illus. nos. 1 through 3 and 6) 875313 Stainless Steel Right Hand Insulated Front Panel Assembly Complete (includes illus. nos. 1 through 3 and 6) 154215 1/4”...

  • Page 14: Plastic" Main Door Assembly

    Illus. No. Part No. Qty. Description 881421 Gray Plastic Main Door Assembly Complete with Mechanical Fasteners (includes illus. nos. 1 and 5 through 9) 800448 12-1/2” Stainless Steel Main Door Hinge Assembly 150410 #10-24 x 3/8” Phillips Pan Head Taptite Screw 152014 1/4-20 Free Spin Wash Nut 102349...

  • Page 15: Main Door Switch Housing For Plastic Door

    Main Door Switch Housing for Plastic Door Illus. No. Part No. Qty. Description 152013 #6-32 Hex Nut 153008 #6 Lock Washer 137005 Single-Pole Door Switch 121028 Insulated Female Terminal 154281 3/8” Standard Nylon Spacer 800448 12-1/2” Stainless Steel Main Door Hinge Assembly (includes illus.

  • Page 16: Main Door "Cold Rolled Steel (Crs)" Assembly

    Illus. No. Part No. Qty. Description 881150 Black Main Door Assembly Complete (includes illus. nos. 1, 2, and 8 through 15) 102354 Door Gasket 170730 Clear Glass Adhesive (10.3 oz. cartridge) 170731 Black Glass Adhesive (10.3 oz. cartridge) 881152 Black Top Hinge Block Assembly (includes illus.

  • Page 17: Main Door Switch Assembly Cold Rolled Steel (Crs) Door

    Main Door Switch Assembly Cold Rolled Steel (CRS) Door Illus. No. Part No. Qty. Description 153566 #6-32 x 7/8” Clinch Stud 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Single-Pole Door Switch 122636 Flag Terminal 881211 Main Door Switch Housing 150301 #8-18 x 7/16”...

  • Page 18: Cold Rolled Steel (Crs) Door Front Panel

    Illus. No. Part No. Qty. Description 881270* Right Hand Front Panel Assembly (cold rolled steel [CRS] door) (includes illus. nos. 1 through 3) 881288 Stainless Steel Front Panel Assembly (cold rolled steel [CRS] door) (includes illus. nos. 1 through 3) 881996* Left Hand Front Panel Assembly (cold rolled steel [CRS] door) (includes illus.

  • Page 19: Basket (Tumbler)/Support Assemblies

    Basket (Tumbler)/Support Assemblies Illus. No. Part No. Qty. Description 800708 Basket (tumbler) ONLY without Felt Collar 800857 Stainless Steel Basket (tumbler) ONLY without Felt Collar 800816 Non-Reversing Basket (tumbler) and Support Assembly Complete (includes illus. nos. 1 through 10) 800819 Reversing Basket (tumbler) and Support Assembly Complete (includes illus.

  • Page 20: Drop Lint Door Assembly Without Trim

    Illus. No. Part No. Qty. Description 800150 Knob Latch Kit Assembly (includes illus. nos. 1 and 2) 160200 Knob Latch ONLY with 2 Screws (without cam) 160003 Dummy Lock ONLY (for non-coin models) 160104 MK-100 Key ONLY (for dummy lock) 160008 Lock Cam for AD-100 and Dummy Lock 160009...

  • Page 21: Drop Lint Door Assembly With Trim

    Drop Lint Door Assembly With Trim For ALL Coin Models Illus. No. Part No. Qty. Description 160001 AD-100 Lock Assembly with Key (for coin models Only) 160103 AD-100 Key ONLY 800150 Knob Latch Kit Assembly (includes illus. nos. 1 and 2) 160200 Knob Latch ONLY with 2 Screws (without cam) 160003...

  • Page 22: Lint Trap Assembly

    Illus. No. Part No. Qty. Description 800472 Non-Reversing Lint Trap Assembly Complete (includes illus. nos. 1 and 3 through 5) 800473 Reversing Lint Trap Assembly Complete (includes illus. nos. 1 and 3 through 5) 850187 Non-Reversing Lint Trap ONLY 850188 Reversing Lint Trap ONLY 154200 5/32”...

  • Page 23: Idler Bearing Assembly

    Idler Bearing Assembly Illus. No. Part No. Qty. Description 100165 5L-610 V-Belt (idler to basket [tumbler]) for Non-Reversing Models ONLY 100106 5L-690 V-Belt (idler to basket [tumbler]) for Reversing Models ONLY 101140 14” x 3” Compound Pulley 100166 4L-790 V-Belt (idler to motor) 60 Hz (for non-reversing models Only) 100167 4L-800 V-Belt (idler to motor) 50 Hz (for non-reversing models Only) 100109...

  • Page 24: Basket (Tumbler) Bearing Assembly

    Basket (Tumbler) Bearing Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 25 Basket (Tumbler) Bearing Assembly Illus. No. Part No. Qty. Description 880220 1-3/8” Flange Bearing 153005 3/8” Lock Washer 152005 3/8-16 Hex Nut 882544 Pillow Block Bearing Assembly Complete (includes illus. nos. 4 through 14 and 20) 882545 Bearing Assembly Complete with Rotational Sensor (includes illus.

  • Page 26: Non-Reversing T.e.f.c. Motor Mount Assembly

    Non-Reversing T.E.F.C. Motor Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 27 Non-Reversing T.E.F.C. Motor Mount Assembly Illus. No. Part No. Qty. Description 100117 4L-620 V-Belt (motor to idler) 100701 3/16” x 3/16” x 1” Key 101133 5/8” x 2-1/4” Motor Pulley (for 60 Hz models Only) 101130 5/8” x 2-1/2” Motor Pulley (for 50 Hz models Only) 150501 5/16-18 x 3/4”...

  • Page 28: Reversing T.e.f.c. Motor Mount Assembly

    Reversing T.E.F.C. Motor Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 29: Reversing T.e.f.c. Motor Mount Assembly

    Reversing T.E.F.C. Motor Mount Assembly Illus. No. Part No. Qty. Description 100114 4L-630 V-Belt (to idler assembly) 100701 3/16” x 3/16” x 1” Key 101130 5/8” x 2-1/2” Motor Pulley (for 60 Hz models Only) 101139 5/8” x 2-3/4” Motor Pulley (for 50 Hz models Only) 120200 3/8”...
  • Page 30 Sensor Bracket Assemblies American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 31: Sensor Bracket Assemblies

    Sensor Bracket Assemblies Illus. No. Part No. Qty. Description 880251 1/4” Temperature Sensor Probe Assembly (includes illus. nos. 1 and 5 through 8) 130103 225° F Manual Reset Thermostat 153010 #6 Star Washer 152000 #6-32 Hex Nut 121028 Insulated Terminal ONLY 122701 Socket Terminal ONLY 112801...

  • Page 32: Direct Spark Ignition (Dsi) Burner Assembly

    Illus. No. Part No. Qty. Description 882898 Natural Gas Burner Assembly Complete For Models Mfd. with Natural Gas ONLY (includes illus. nos. 1 through 31) 882899 Liquid Propane (L.P.) Gas Burner Assembly Complete For Models Mfd. with Liquid Propane (L.P.) Gas ONLY (includes illus.

  • Page 33: Direct Spark Ignition (Dsi) Burner Assembly

    1/2” 24 VAC Redundant (natural gas) Gas Valve 880960 1/2” 24 VAC Direct Spark Ignition (DSI) Liquid Propane (L.P.) Gas Valve Assembly 882230* ADG-758 Direct Spark Ignition (DSI) Liquid Propane (L.P.) Conversion Kit 140819* #30 Burner Orifice (natural gas) 140803* #49 Burner Orifice (liquid propane [L.P.] gas) 150103 #8-32 x 1/2”...

  • Page 34: For Models Mfd. Prior To April 15, 2000

    For Models Mfd. with Liquid Propane (L.P.) Gas ONLY (includes illus. nos. 1 through 5 and 7 through 32) 814832 Burner Box ONLY 882230** ADG-758 Direct Spark Ignition (DSI) Liquid Propane (L.P.) Conversion Kit 141105 Large Burner Tube 141210 4-Port Manifold...

  • Page 35: For Models Mfd. Prior To April 15, 2000

    Direct Spark Ignition (DSI) Burner Assembly For Models Mfd. prior to April 15, 2000 Illus. No. Part No. Qty. Description 150300 #10-16 x 1/2” Hex Washer TEK Screw 140819** #30 Burner Orifice (natural gas) 140803** #49 Burner Orifice (liquid propane [L.P.] gas) 150103 #8-32 x 1/2”...

  • Page 36: Single-Phase (1Ø) Motor, Electric Relay Panel Assembly

    Single-Phase (1Ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 132475 2-Pole Contactor - 24 VAC 150299 #10 x 1” Hex Washer TEK Screw 824828 RC Network with Connectors (for microprocessor controller [computer] models Only) 322809 Back Electrical Box Cover...Not Illustrated 150301 #8-18 x 7/16”...

  • Page 37: 3-Phase (3Ø) Motor, Electric Relay Panel Assembly

    3-Phase (3Ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 322812 Back Electrical Box Component Plate 132430 Impellor Contactor (208/230/240v, 50/60 Hz) 24 VAC 137015 RC Network (for microprocessor controller [computer] models Only) 150103 #8-32 x 3/4” Phillips Round Head Machine Screw 151001 #8-32 Pal Nut 153002...

  • Page 38: Microprocessor Reversing Rear Control Box Assembly

    Microprocessor Reversing Rear Control Box Assembly Illus. No. Part No. Qty. Description 322812 Back Electrical Box Component Plate 137060 Arc Suppressor (A.S.) Board 137013 Nylon Standoff 882386 Reversing Contactor (208/230/240v, 50/60 Hz) 24 VAC 150103 #8-32 x 3/4” Phillips Round Head Machine Screw 151001 #8-32 Pal Nut 153002...

  • Page 39: Dual Timer Reversing Rear Control Box Assembly

    Dual Timer Reversing Rear Control Box Assembly Illus. No. Part No. Qty. Description 322812 Back Electrical Box Component Plate 132198 Reversing Timer (50/60 Hz) 24 VAC 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 882386 Reversing Contactor (208/230/240v, 50/60 Hz) 24 VAC 150103 #8-32 x 3/4”...

  • Page 40: Outer Top/Back Guard Assemblies

    Illus. No. Part No. Qty. Description 322809 Rear Electrical Box Cover 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 323738 Top Back Guard 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 312527 Outer Top Guard 314514...

  • Page 41: Microprocessor Coin Acceptors Listing

    Microprocessor Coin Acceptors Listing NOTE: Coin acceptors listed include optical switch (ADC Part No. 137056 Greenwald). Coin acceptors listed include optical switch (ADC Part No. 881143 Hanke). ADC Part No. Nation 882689 United States 125100 U.S. and Canada 125107 Australia...

  • Page 42: Step Down Transformer Usage Listing

    STEP DOWN TRANSFORMER Heat American Dryer Corporation Step Down Transformer Usage Listing USAGE LISTING Wire Voltage Service 460/480 460/480 88 Currant Road / Fall River, MA 02720-4781 Transformer Part No. 132059 132059 132062 132062 132053 132053 132050...

  • Page 43: Additional Parts Available

    Additional Parts Available Part No. Description 112039 “Black/White/Green Ground” Label 112280 “ Clean Lint Screen” Label 112534 “Phase 5 OPL Program Location Summary” Label 114001 “CAUTION - Exhaust/Lint Screen” Label 114006 “WARNING - Fire Hazards” Label 114095 “MOP HEAD WARNING” Label 117505 Aluminum Duct Tape (sold by the foot) 120100...
  • Page 44 ADC 450419 1 - 12/17/99-30 2 * 08/22/01-25 3 - 09/04/02-5 4 * 01/08/03-20...
