Direct Spark Ignition (Dsi) Burner Assembly - ADC ADG-758 Parts Manual

Direct Spark Ignition (DSI) Burner Assembly

For Models Mfd. as of April 15, 2000
Illus. No. Part No.
5 128927
880960
882230*
6 140819*
140803*
7 150103
8 151001
9 150300
10 809309
11 150309
12 152013
13 128935
14 817027
15 142707
16 142506
17 142600
18 142809
19 319704
20 151000
21 150001
22 130201
23 318700
24 143000
25 154004
26 802799
27 122200
28 150303
29 105500
30 319202
31 154002
** 882772
* Consult factory for elevations over 2,000 feet.
** Needed when converting from steam to gas heat.
Telephone: (508) 678-9000
Qty. Description
1 1/2" 24 VAC Redundant (natural gas) Gas Valve
1 1/2" 24 VAC Direct Spark Ignition (DSI) Liquid Propane (L.P.)
Gas Valve Assembly
1 ADG-758 Direct Spark Ignition (DSI) Liquid Propane (L.P.) Conversion Kit
4 #30 Burner Orifice (natural gas)
4 #49 Burner Orifice (liquid propane [L.P.] gas)
4 #8-32 x 1/2" Pan Head Machine Screw
4 #8-32 Pal Nut
5 #10-16 x 1/2" Hex Washer TEK Screw
1 Ignitor Probe Assembly with 19" Leads
9 #10-16 x 1/2" Hex Head TEK Crimptite Screw
2 #6-32 Hex Nut
1 Direct Spark Ignition (DSI) Module with 3 Tries
1 Johnson Controls Direct Spark Ignition (DSI) Module Mounting Bracket
4 1/2" x 1-1/2" Long Black Nipple
1 1/2" Street Elbow
1 1/2" Black Union
1 1/2" x 29-1/8" Nipple
1 Hi-Limit Mounting Bracket
2 #6-32 Pal Nut
2 #6-32 x 1/2" Phillips Round Head Machine Screw
1 330º Hi-Limit Manual Reset
1 Pipe Bracket (bent)
1 3/4" to 1/2" Reducing Coupling
1 Twin Speed Nut
1 Sail Switch Box Cover and Bracket ONLY
1 Sail Switch ONLY
2 #4 x 3/4" Pan Head "A" Machine Screw
1 Sail Switch Actuator Rod
1 Sail Switch Damper (flat)
1 1/8" Push On Fastener
1 Steam to Gas Interface Plate...Not Illustrated
(continued)
