Reversing T.e.f.c. Motor Mount Assembly - ADC ADG-758 Parts Manual

Reversing T.E.F.C. Motor Mount Assembly

Illus. No. Part No.
1 100114
2 100701
3 101130
101139
4 120200
5 181003
6 150501
7 153002
8 153001
9 100007*
10 120200
11 150501
12 153002
13 153001
14 154000
15 152004
16 153002
17 153001
18 850021
804026**
--------
19 117604
20 153051
21 100714
22 100604
23 153050
24 152006
* Check part number on motor data label to verify correct motor.
** Specify voltage when ordering.
*** Contact factory for information.
**** As required.
Telephone: (508) 678-9000
Qty. Description
1 4L-630 V-Belt (to idler assembly)
1 3/16" x 3/16" x 1" Key
1 5/8" x 2-1/2" Motor Pulley (for 60 Hz models Only)
1 5/8" x 2-3/4" Motor Pulley (for 50 Hz models Only)
1 3/8" x 90° Connector
1 1/2 HP 208/230/380/460v 3ø 50/60 Hz Totally Enclosed, Fan-Cooled
(T.E.F.C.) Motor (56Z frame)
4 5/16-18 x 3/4" Hex Head Machine Bolt
4 5/16" Lock Washer
4 5/16" Flat Washer
1 1/2 HP 220/230/380/460v 3ø 50/60 Hz Totally Enclosed, Fan-Cooled
(T.E.F.C.) Motor (56Z frame)
1 3/8" x 90° Connector
4 5/16-18 x 3/4" Hex Head Machine Bolt
4 5/16" Lock Washer
4 5/16" Flat Washer
8 5/16" Tinnerman Nut
7 5/16" Hex Nut
7 5/16" Lock Washer
7 5/16" Flat Washer
1 Reversing Motor Mount ONLY (56Z frame)
1 60 Hz Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount
Assembly Complete
(includes illus. nos. 2 through 14 and 18 through 24)
*** 50 Hz Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount
Assembly Complete
(includes illus. nos. 2 through 14 and 18 through 24)
4 Neoprene Sponge Tape (sold by the foot)
1 3/4" S.A.E. Flat Washer
1 3/16" x 3/16" x 1-7/8" Key
1 12-1/2" Impellor
**** 1/2" S.A.E. Flat Washer
2 1/2-20 Left Hand Jam Nut
27
