Mount the Ceiling Bracket to the ceiling using the
2.
Mounting Screw (x 4) included or the appropriate hardware.
When the Ceiling Plate is installed in a ceiling, slide both
3.
piecies of the Ceiling Plate Cover back over-top of the
Ceiling Plate, snapping them together.
Align the Mounting Arms with the Mounting Holes on the
4.
top of the Projector.
Select the appropriate Installation Screws (M3 x 24 mm, M4
5.
x 24mm, M5 x 24 mm, or M6 x 24 mm).
Insert the selected Installation Screw (x 4), through the
6.
Mounting Holes in the Mounting Arms and into the
Mounting Holes on the Projector.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Removing the Ceiling Plate Cover
29
