StarTech.com LAPTOP-SIT-STAND Manual

Ergonomic Adjustable Laptop Sit Stand Desk Converter

Product Diagram (LAPTOP-SIT-STAND)

Front View
2
1
Bottom View
5
Component
1 Slide Button • Push-in to Raise or Lower the workstation
2 Workstation Surface • Place a laptop, keyboard, and a mouse
• Supports the workstation. Adjusts the Height in Six
3
Upper Frame
Different Positions from 1.8 to 15.9 in (45 to 405 mm)
• Stabilizes the workstation. Foam pads at the bottom
4 Lower Frame
protect the desk surface
• Helps prevent trapping your fingers when Lowering
5
Finger Guard
the workstation
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support
3
4
Function

Package Contents

• Desktop Sit-Stand Workstation x 1
• Quick-Start Guide x 1

Requirements

For the latest manuals, product information, technical specifications, and declarations of
conformance, please visit: www.startech.com/LAPTOP-SIT-STAND

Installation

WARNINGS!
Do not exceed the weight capacity of this product. Overloading this product might
result in injury or property damage. This product can support the following weight: up
to 17.6 lb (8 kg).
When adjusting the height of this product, ensure that the mounted equipment is
properly secured and the weight is supported until the locking mechanism is fully
engaged. Adjust the height at a slow speed to prevent any equipment instability.
Failure to follow these guidelines may result in property damage and/or personal
injury.
Stored Energy Hazard! This product contains a spring mechanism that can cause the
assembly and/or mounted equipment to move forcibly and quickly upwards when the
slide button is pressed.
Pinch Hazard! Keep your fingers clear from moving components. Do not place your
fingers past the finger guard at the bottom of the workstation surface when lowering
it.
1. Cut the security plastic Tie that Holds the Upper Frame to the Lower Frame .
2. Carefully Remove the foam Pad installed on the Slide Button.

Operation

When adjusting the height of this product, always use two hands to ensure a
controlled movement.
If the slide button is pushed in and without releasing, you can adjust the height of the
upper frame in one movement to any of the available height positions. Until the slide
button is released, the height of the upper frame cannot be locked.
Due to the spacing of the locking holes, the user must continue to support the
workstation weight until the locking mechanism is engaged.

Quick-Start Guide

Manual Revision: May 18, 2022 3:20 PM
