IC-KP-B5-V23
Commands
<Month>
<P>
<PSW>
<ReplyCounter>
<Sensor channel>
<Status>
<T>
<TagType>
<Trigger mode>
<WordAddr>
<WordNum>
<Year>
7.9

Fault/Status messages

Status
00h
FFh
Error messages which triggered the identification system
Status
01h
02h
03h
04h
05h
06h
07h
08h
09h
0Ah
72
: 2 bytes ASCII, hexadecimal encoding, 01 ... 0C (01=January,
0C=December)
: 1 bit, password mode, 0 (0b): Mode off, 1 (1b): Mode on
: 4 bytes HEX, password
: 1 byte, increases by 1 after each response and confirmation. The
reply counter starts from 0 after the system is switched on.
When the maximum value is reached, the counter skips the value 0
(from 255 to 1).
: 3 bits, channel
3 (011b) or 4 (100b)
: 1 byte (see chapter 7.9)
: 1 bit, toggle bit
: 2 ASCII characters, for example: '02' for IPC02
: 8 bits
0 (00000000b): Trigger mode off
1 (00000001b): Trigger mode on
2 (00000010b): Trigger mode inverted
: 2 bytes, word start address in the data carrier, range from 0000h to
FFFFh, depending on tag type.
: 4 bits, number of words to be read or written, range from 0h to Fh,
depending on tag type.
The following applies for IPC03: The word count 0h is used with the
word address 0000h to read the preset data range on the read/write
tag ("Default Read").
: 2 bytes ASCII, hexadecimal encoding, 00h ... 63h
Meaning
The command has been executed without error.
The command is processing.
Meaning
The battery of the read/write tag is weak.
Reserved
Reserved
Incorrect or incomplete command or parameter not in the valid range.
No data carrier in the detection range.
Hardware error, e.g. error during self-test or R/W head defect.
Internal device error.
Reserved
The parameterized tag type is not compatible with the connected reading head.
Several tags in the detection range (UHF).
