IC-KP-B5-V23
Commands
7.5

System commands

Change tag (CT)
Command:
Byte
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Response:
Byte
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
This command tells the read/write head on the relevant channel which tag type to
communicate with. This setting is stored in the non-volatile memory on the unit.
Supported tag types
Tag type P+F
designation
High Low
byte byte
'0' '2' IPC02
'0' '3' IPC03
'1' '1' IPC11
28
Content
Command code (04h)
Reserved/Ident channel/Toggle bit
Data carrier type in ASCII
Data carrier type in ASCII
not used
not used
not used
not used
Content
Command code (04h)
Reserved/Ident channel/Toggle bit
Status
Reply counter
not used
not used
not used
not used
Chip type
Unique, EM4102 (EM
Microelectronic)
EM4450 (EM
Microelectronic), Titan
Q5 (Sokymat)
Bit no.
7 6 5 4
0 0 0 0
- - - -
<TagType> (high byte)
<TagType> (low byte)
- - - -
- - - -
- - - -
- - - -
Bit no.
7 6 5 4
0 0 0 0
- - - -
<Status>
<ReplyCounter>
- - - -
- - - -
- - - -
- - - -
Access Writable
memory
[bytes]
fixcode 5
R/W fixcode 116
R/W 5
3 2 1 0
0 1 0 0
<Channel> <T>
- - - -
- - - -
- - - -
- - - -
3 2 1 0
0 1 0 0
<Channel> <T>
- - - -
- - - -
- - - -
- - - -
Read only Frequency
code length range
[byte]
5 125 kHz
4 125 kHz
- 125 kHz
