IC-KP-B5-V23
Commands
Enhanced buffered write fixcode (EX)
Command:
Byte
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
...
Byte N
Table 7.8: 1) N = <FixLen> + 3
Response:
Byte
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
The R/W head constantly attempts to write a read only code. After each
successful write, the response is sent and the system waits until a new tag is
within the detection range. The command then starts again from the beginning.
IPC11:
IDC-...-1K: <FixLen>
58
Content
Command code (24h)
FixLen/Ident channel/Toggle bit
FixType
FixType
Data 00h ... FFh
Data 00h ... FFh
Data 00h ... FFh
1)
Content
Command code (24h)
FixLen/Ident channel/Toggle bit
Status
Reply counter
not used
not used
not used
not used
<FixLen> = 5
<FixType> = '02' ASCII (30h 32h), the read only code cannot be changed
'11' ASCII (31h 31h), the read only code can be overwritten
= 7
The first 3 bytes are hexadecimal (0h ... Fh), the last 4 bytes
are decimal (0d ... 9d).
<FixType> = '52' ASCII (35h 32h), the read only code can be overwritten
<Data> = (Byte 1 to 3): 0x30 ... 0x39; 0x41...0x46
(Byte 4 to 7): 0x30...0x39
Bit no.
7 6 5 4 3
0 0 1 0 0
<FixLen> <Channel>
<FixType> (high byte)
<FixType> (low byte)
<Data>
<Data>
<Data>
Bit no.
7 6 5 4 3
0 0 1 0 0
<FixLen> <Channel>
<Status>
<ReplyCounter>
- - - - -
- - - - -
- - - - -
- - - - -
2 1 0
1 0 0
<T>
2 1 0
1 0 0
<T>
- - -
- - -
- - -
- - -
