IC-KP-B5-V23
Technical specifications
LC Display
Buttons
Electrical data
Rated operational
voltage U
e
Ripple
Current consumption
Power consumption P
Galvanic isolation
Interface
Physical
Protocol
ID code
Transfer rate
Conformity
Electromagnetic
compatibility
Degree of protection
Ambient conditions
Ambient temperature
Storage temperature
Climatic conditions
Shock and impact
resistance
Mechanical data
Degree of protection
Connection
Housing material
Mounting
Weight
Two-line multifunction display with 12 characters per line
Configuration of the control interface and display of
connected R/W heads as additional pictograms
Simple, direct command input and addressing possible
4 buttons: ESC, up, down and return
20 ... 30 V DC , PELV
≤ 10 % at 30 V DC
≤ 2 A incl. R/W heads
3.5 W without R/W heads
0
Basic insulation in accordance with DIN EN 50178, rated
insulation voltage 50 V
RS 485
INTERBUS remote bus
03
500 kBit/s or 2 MBit/s can be switched internally
EN 61000-6-2, EN 61000-6-4,
EN60529
-25 ... 70 °C (248 ... 343 K)
-30 ... 80 °C (243 ... 353 K)
Max. relative humidity 96%
Oscillation (sine): 5 g, 10 ... 1000 Hz to EN 60068-2-6
Shock (half-sine): 30 g, 11 ms to EN 60068-2-27
IP65 in accordance with EN 60529
R/W heads: Shielded, 4-pin, M12 connector
Power supply: M12 connector
Ground: M6 grounding screw
INTERBUS: Connector, male: Incoming interface
Socket: Outgoing interface
Aluminum, powder-coated
Snap on to 35 mm DIN mounting rail or screw mounting
Approx. 1000 g
eff
