EMAC Module Registers

5.23 Receive Unicast Clear Register (RXUNICASTCLEAR)

The receive unicast clear register (RXUNICASTCLEAR) is shown in
31
15
7 6
RXCH7EN RXCH6EN
R/W1C-0 R/W1C-0
LEGEND: R/W = Read/Write; R = Read only; W1C = Write 1 to clear (writing a 0 has no effect); -n = value after reset
Table 60. Receive Unicast Clear Register (RXUNICASTCLEAR) Field Descriptions
Bit Field Value
31-8 Reserved 0
7 RXCH7EN 0-1
6 RXCH6EN 0-1
5 RXCH5EN 0-1
4 RXCH4EN 0-1
3 RXCH3EN 0-1
2 RXCH2EN 0-1
1 RXCH1EN 0-1
0 RXCH0EN 0-1
106
EMAC/MDIO Module
Figure 61. Receive Unicast Clear Register (RXUNICASTCLEAR)
5 4
RXCH5EN RXCH4EN
R/W1C-0 R/W1C-0
Description
Reserved
Receive channel 7 unicast enable clear bit. Write 1 to clear the enable, a write of 0 has no effect.
Receive channel 6 unicast enable clear bit. Write 1 to clear the enable, a write of 0 has no effect.
Receive channel 5 unicast enable clear bit. Write 1 to clear the enable, a write of 0 has no effect.
Receive channel 4 unicast enable clear bit. Write 1 to clear the enable, a write of 0 has no effect.
Receive channel 3 unicast enable clear bit. Write 1 to clear the enable, a write of 0 has no effect.
Receive channel 2 unicast enable clear bit. Write 1 to clear the enable, a write of 0 has no effect.
Receive channel 1 unicast enable clear bit. Write 1 to clear the enable, a write of 0 has no effect.
Receive channel 0 unicast enable clear bit. Write 1 to clear the enable, a write of 0 has no effect.
© 2011, Texas Instruments Incorporated
Figure 61
Reserved
R-0
Reserved
R-0
3 2
RXCH3EN RXCH2EN
R/W1C-0 R/W1C-0
www.ti.com
and described in Table 60.
16
8
1 0
RXCH1EN RXCH0EN
R/W1C-0 R/W1C-0
