5.22 Receive Unicast Enable Set Register (RXUNICASTSET)

The receive unicast enable set register (RXUNICASTSET) is shown in
Table
59.
Figure 60. Receive Unicast Enable Set Register (RXUNICASTSET)
31
15
7
6
RXCH7EN
RXCH6EN
R/W1S-0
R/W1S-0
LEGEND: R/W = Read/Write; R = Read only; W1S = Write 1 to set (writing a 0 has no effect); -n = value after reset
Table 59. Receive Unicast Enable Set Register (RXUNICASTSET) Field Descriptions
Bit
Field
Value
31-8
Reserved
0
7
RXCH7EN
0-1
6
RXCH6EN
0-1
5
RXCH5EN
0-1
4
RXCH4EN
0-1
3
RXCH3EN
0-1
2
RXCH2EN
0-1
1
RXCH1EN
0-1
0
RXCH0EN
0-1
SPRUFL5B – April 2011
Submit Documentation Feedback
Reserved
Reserved
5
4
RXCH5EN
RXCH4EN
R/W1S-0
R/W1S-0
Description
Reserved
Receive channel 7 unicast enable set bit. Write 1 to set the enable, a write of 0 has no effect.
May be read.
Receive channel 6 unicast enable set bit. Write 1 to set the enable, a write of 0 has no effect.
May be read.
Receive channel 5 unicast enable set bit. Write 1 to set the enable, a write of 0 has no effect.
May be read.
Receive channel 4 unicast enable set bit. Write 1 to set the enable, a write of 0 has no effect.
May be read.
Receive channel 3 unicast enable set bit. Write 1 to set the enable, a write of 0 has no effect.
May be read.
Receive channel 2 unicast enable set bit. Write 1 to set the enable, a write of 0 has no effect.
May be read.
Receive channel 1 unicast enable set bit. Write 1 to set the enable, a write of 0 has no effect.
May be read.
Receive channel 0 unicast enable set bit. Write 1 to set the enable, a write of 0 has no effect.
May be read.
© 2011, Texas Instruments Incorporated
Figure 60
R-0
R-0
3
2
RXCH3EN
RXCH2EN
R/W1S-0
R/W1S-0
EMAC Module Registers
and described in
16
8
1
0
RXCH1EN
RXCH0EN
R/W1S-0
R/W1S-0
105
EMAC/MDIO Module
