Performer Profile IP Q4

Cleaning

Please follow the recommendations when cleaning and inspecting lenses and reflectors:
Do not use glass or window type cleaners on lenses (glass or polymer) or reflectors.
Do not use abrasive materials such as steel wool.
Replace lenses if they contain visible damage (cracks or deep scratches) that may impair their
effectiveness.

Cleaning the Glass Lenses

01) Loosen the 4 cover mounting screws (05). Remove the lens tube.
02) Dampen a clean lint-free cloth with vinegar or household ammonia. You may also use water, but it
will leave spots that can be removed by gently polishing the lens with a clean and dry cloth.
03) Starting from the center, gently wipe the lens.
04) Slide the lens tube back into the barrel. Tighten the 4 cover mounting screws.

Cleaning the Reflector

Unplug the fixture before attempting to clean the reflector. To quickly clean the
reflector, remove the lens tube and clean the dust from the reflector with a blast of oil-
free air.
You may also wipe the reflector with a clean lint-free cloth. If either method is not
sufficient, follow the instructions below.
01) Loosen the 4 cover mounting screws (05). Remove the lens tube.
02) Dampen a clean lint-free cloth with alcohol or distilled water (alcohol is recommended).
03) Gently wipe the reflector.
04) Slide the lens tube back into the barrel. Tighten the 4 cover mounting screws.
Order code: 33111
