Performer Profile IP Q4

Description of the device

Features
The Showtec Performer Profile IP Q4 is an IP-rated theater spotlight fixture with high output and great
effects.
● Input voltage: 110–240 V AC, 50/60 Hz
● Power consumption: 300W@FO
● Light source: 1 x 250W LED Array RGBW
● Drive current: 1,2A
● Light output: 9975 lx @ 3 m (15º)
● DMX Channels: HSIC (8CH), Simple (9CH), Colour 8Bit (12CH), Colour 16Bit (17CH)
● Control: Static, Manual, Master/Slave, DMX-512/RDM
● Refresh rate: 600 Hz–25 kHz
● CCT: 2700-8000K
● Dimmer: 0–100 %
● Strobe: 0–25 Hz
● Dimming curves: Dimm4 technology, 4 presets
● Dimming resolution: 16 bit
● Beam angle: 15º–30º
● Zoom: Electrical
● Focus: Electrical
● Gobo (included): 66 mm/49,5 mm (M size)
● Connections: Dedicated IP True1 pro power connector IN, IP 3-pin XLR signal connectors IN/OUT
● Housing: Die-cast aluminum
● Cooling: Fan
● Color: Black, powder-coated
● IP rating: IP65
● Dimensions: 650 x 340 x 575 mm (LxWxH)
● Weight: 13,74 kg

Overview

01) Lens tube cover
02) Safety eyes
03) Mounting bracket
04) Adjustment screw
05) Lens tube cover mounting screws
06) Lens
Order code: 33111
7
Fig. 01
