Summary of Contents for SHOWTEC LED Messenger
- Page 1 LED Messenger ORDERCODE 43029...
- Page 2 For more information: iwant@showtec.info You can get some of the best quality, best priced products on the market from Showtec. So next time, turn to Showtec for more great lighting equipment. Always get the best -- with Showtec ! Thank you!
-
Page 3: Table Of Contents
Claims……………………………………………………………………………............Description................…...………………………………………….…………. Features and Overview ………………………………...….……………….………….……….……….…………….. Backside…………………………………………………...…...….……………….…………………...….…………….. Installation................…...…………………………………….………………. Set Up and Operation..............……..…………………………………………….. Control Modes…………………………………………………………………………………………………….……… One LED Messenger (Built-in Programs)…..………………………………………….………………….…….. One LED Messenger (Auto Run Mode)……………………………………………….……………….………. One LED Messenger (Sound Control)…………………………………………………………………..……… Multiple LED Messengers (Master/Slave control).……………………………………………………...……. Multiple LED Messengers (DMX control)………………………………………………………………..………... -
Page 4: Warning
Your shipment includes: • LED Messenger with cable 1,5m and hanging-bracket • remote control and 1,5m cable with IR eye • User manual LED Expected Lifespan LEDs gradually decline in brightness over time. - Page 5 If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 6: Operating Determinations
Always let the installation be carried out by an authorized dealer ! Procedure: If the LED Messenger is lowered from the ceiling or high joists, professional trussing systems have to be used. Use a clamp to mount the LED Messenger, with the mounting-bracket, to the trussing system. -
Page 7: Return Procedure
Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 8: Description
Description of the device Features The Showtec LED Messenger is a light effect with high output and great effects. • Multi programmable RGB graphic patterns • Multi programmable RGB Text patterns • Operating Modes: built-in programs, Auto run, DMX, Sound active, Master/Slave •... -
Page 9: Installation
One LED Messenger (Sound-control) 1.Plug the end of the electric mains power cord into a proper electric power supply socket. Turn on the music. If the device is set to SOUN, then the LED Messenger will react to the beat of the music. -
Page 10: Multiple Led Messengers (Dmx Control)
Multiple Messengers (Master/Slave control) Fig. 3 Multiple LED Messenger (DMX Control) Plug the end of the electric mains power cord into a proper electric power supply socket. 2. Use a 3-p XLR cable to connect the Messengers. 3. Link the units as shown in (figure 4), Connect a DMX signal cable from the first unit's DMX "out" socket to the second unit's "in"... -
Page 11: Fixture Linking
Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support. -
Page 12: Control Panel
When using multiple LED Messenger’s, make sure you set the DMX addresses right. Therefore, the DMX address of the first LED Messenger should be 1(A001); the DMX address of the second LED Messenger should be 1+3=4; the DMX address of the third LED Messenger should be 4+3=7, etc. -
Page 13: Menu Overview
Menu Overview Built-in Programs Operation by using the buttons on the device 1) Press the MODE button, until the LED displays show PrXX. You can select the built-in programs by pressing the Up/Down buttons. Note: Pr is the abbreviation of programs. Pr01: Selection of 15 phrases (10 built-in phrases and 5 user-defined phrases) 2) When you have pressed the MODE button and the display shows Pr01. -
Page 14: Operation By Using The Ir Remote Control
Pr02 - Pr22: Built-in effect programs 1) When you have pressed the MODE button and the display shows Pr02 to Pr22. 2) Press the SET UP button once, the display will show SXXX. You can now set speed from S001 to S100 by pressing the Up/Down buttons. 3) Press the SET UP button twice, the display will show FXXX. -
Page 15: Auto Run Mode
Auto Run Mode Operation by using the buttons on the device 1) Press the MODE button on the device, until the display shows AUTO. The device is now in auto run mode. 2) Press SET UP button, until the display shows SXXX. You can set the running speed for auto run mode. Press the Up/Down buttons to set the running speed from S001 - S100. -
Page 16: Master/Slave Mode
Master/Slave Mode Master/Slave Operation by using the buttons on the device 1) In order to select MASTER/SLAVE mode, press the MODE button and select SLAV. Master/Slave Operation by using the IR remote control 1) In order to select MASTER/SLAVE mode, press the SLAVE button (O) on the remote. You can use the same functions on the master device as described on page 11-13 (Built-in Programs, Auto Run or Music control). -
Page 17: Dmx Channel Setting
DMX Channel Setting Channel 1 – Built-in Programs 1-10 Program 1 11-21 Program 2 22-32 Program 3 33-43 Program 4 44-54 Program 5 55-65 Program 6 66-76 Program 7 77-87 Program 8 88-98 Program 9 99-109 Program 10 110-120 Program 11 121-131 Program 12 132-142... -
Page 18: Maintenance
3. If all of the above appears to be O.K., plug the unit in again. 4. If you are unable to determine the cause of the problem, do not open the LED Messenger, as this may damage the unit and the warranty will become void. -
Page 19: No Response To Dmx
No Response to DMX Response: Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction. 1. Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power. Try your DMX control again. 2. -
Page 20: Product Specifications
Product Specification Model: Showtec LED Messenger Power: 240V-50Hz (CE) Power consumption: 60 Watt Multi programmable RGB graphic patterns Multi programmable RGB Text patterns IR remote control DMX-controlled 3-pin DMX In and 3-pin DMX Out Compact strong metal housing Beam angle: 15degree...
