9. Troubleshooting

9.4. Network Variables - Overview

9.4.1. Output variables (nvo)
Variable function
Status word
Drive output [%]
Drive output [Hz]
kWh counter
DC Link Voltage
Motor thermal
Inverter Thermal
Closed loop feed-
back
Fanbelt broken
Alarm flag
Warning flag
Alarm word
Warning word
Extended status-
word
9
Digital inputs
Analog Input (53)
Analog Input (54)
Analog Input
(X30/11)
Analog Input
(X30/12)
Analog Input
(X42/1)
Analog Input
(X42/3)
Analog Input
(X42/5)
ECB option status
Parameter access
cmd.
Drive Speed
Output current
Output voltage
Output power
Running hours
Object Status
66
Variable name SNVT type
nvoStatusword SNVT_state
nvoOutputPcnt SNVT_lev_percent
nvoOutputHz SNVT_freq_hz
nvoDrvEnrg SNVT_elec_kwh_l
nvoDCVoltage SNVT_volt
nvoTempMtr SNVT_lev_cont
nvoTempInvrtr SNVT_lev_cont
nvoFeedback SNVT_count_inc_f
nvoBrokenBelt SNVT_switch
nvoAlarm SNVT_switch
nvoWarning SNVT_switch
nvoAlarmword SNVT_state_64
nvoWarningword SNVT_state_64
nvoExtendedStsw SNVT_state_64
nvoDigitInput SNVT_state_64
nvoAnIn1 SNVT_volt/SNVT_amp_mil
nvoAnIn2 SNVT_volt/SNVT_amp_mil
nvo101AnIn1 SNVT_volt
nvo101AnIn2 SNVT_volt
nvo109AnIn1 SNVT_volt/SNVT_temp_p
nvo109AnIn2 SNVT_volt/SNVT_temp_p
nvo109AnIn3 SNVT_volt/SNVT_temp_p
nvoECBstatus SNVT_state
nvoParamRes- UNVT_param_response
ponse
nvoDrvSpeed SNVT_lev_percent
nvoDrvCurnt SNVT_amp
nvoDrvVolt SNVT_volt
nvoDrvPwr SNVT_power_kilo
nvoDrvRunHours SNVT_time_hour
nvoStatus SNVT_obj_status
MG.11.E1.02 - VLT ® is a registered Danfoss trademark
VLT® FC 100 LonWorks
FC 100
Profile
par.
FC VSD 16-03
FC VSD 16-05
FC VSD 16-13
FC VSD 15-02
FC VSD 16-30
FC VSD 16-18
FC VSD 16-35
FC VSD 16-52
FC VSD 16-93
FC VSD 16-90
FC VSD 16-03
FC VSD 16-90 +
16-91
FC VSD 16-92 +
16-93
FC VSD 16-94 +
16-95
FC VSD 16-60
FC VSD 16-62
FC VSD 16-64
FC VSD 16-75
FC VSD 16-76
FC VSD 18-30
FC VSD 18-31
FC VSD 18-32
FC VSD 31-10
FC VSD -
VSD 6010 16-05
VSD 6010 16-14
VSD 6010 16-12
VSD 6010 16-10
VSD 6010 15-01
Node obj. -
