VLT® FC 100 LonWorks
Extended Status Word
Variable
name:
nvoExtendedStsw
This variable contains the complete extended status word.
For more detailed information on the Extended Status Word, please refer to the
ing
section of this manual.
Digital Inputs
Variable
name:
nvoDigitInput
This variable contains the status of the digital inputs.
A logical 1, indicates that the input is On or active.
A logical 0, indicates that the input is Off or inactive.
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bit 10-63
Analog Input (53)
Variable
name:
nvoAnIn1
This variable contains the value allocated to the analog input terminal 53.
This terminal can either be configured as a voltage input (0-10 V) or as a current input (0-20 mA),
depending on the setting of switch S 201. The variable type is changeable with the commissioning
tool or LNS Plug-in in order to match the appropriate unit.
SNVT
type:
SNVT_state_64
NB!
Please note that in the representation of the Extended Status Word in the LonMaker
Browser, the Least Significant Bit (LSB) is to the far left.
SNVT
type:
SNVT_state_64
SNVT
type:
Changeable
SNVT_volt
SNVT_amp_mil
MG.11.E1.02 - VLT ® is a registered Danfoss trademark
5. Configuration of the system
Boolean 1 bit x 64
Boolean 1 bit x 64
Digital Input Terminal 33
Digital Input Terminal 32
Digital Input Terminal 29
Digital Input Terminal 27
Digital Input Terminal 19
Digital Input Terminal 18
Reserved for future terminals
Digital Input GP I/O Terminal X30/2
Digital Input GP I/O Terminal X30/3
Digital Input GP I/O Terminal X30/4
Reserved for future terminals
Value:
Min. Max.
0 V 10 V
0 mA 20 mA
State:
Troubleshoot-
State:
Resolution:
0.1 V
0.1 mA
