5. Configuration of the system
5.2.2. Network variable description - FC VSD Profile - output
Status Word
Variable
name:
nvoStatusWord
This variable is a 16-bit word providing status information on the frequency converter. For more
information on the status word, please refer to the
5
Drive Output [%]
Variable
name:
nvoOutputPcnt
In open loop operation, this variable contains the frequency converter output frequency in per-
centage, within the reference range.
In closed loop operation, this variable contains the frequency converter feedback signal, within
the reference range.
Drive Output [Hz]
Variable
name:
nvoOutputHz
This variable displays the actual output of the frequency converter motor frequency in Hz.
kWh Counter [kWh]
Variable
name:
nvoDrvEnrg
This variable contains the power consumption of the motor in kWh measured as a mean value
over a one hour period.
28
SNVT type:
SNVT_state
NB!
Please note that in the representation of the Status Word in the LonMaker Browser,
the Least Significant Bit (LSB) is to the far left.
SNVT
type:
SNVT_lev_percent
SNVT
type:
SNVT_freq_hz
SNVT
type:
SNVT_elec_kwh_l
MG.11.E1.02 - VLT
State:
Boolean 1 bit x 16
Danfoss FC Control Profile
Value:
Min. Max.
-163.840 % +163.840 %
Value:
Min. Max.
0 Hz 6,500 Hz
Value:
Min. Max.
0 kWh 65,535 kWh
® is a registered Danfoss trademark
VLT® FC 100 LonWorks
section.
Resolution:
0.005 %
Resolution:
1 Hz
Resolution:
1 kWh
