VLT® FC 100 LonWorks
Output variables
Variable func-
tion
Status word
Drive output [%] nvoOutputPcnt
Drive output [Hz] nvoOutputHz
kWh counter
DC Link Voltage
Motor thermal
Inverter Thermal nvoTempInvrtr
Closed loop feed-
back
Fanbelt broken
Alarm flag
Warning flag
Alarm word
Warning word
Extended status-
word
Digital inputs
Analog Input (53) nvoAnIn1
Analog Input (54) nvoAnIn2
Analog Input
(X30/11)
Analog Input
(X30/12)
Analog Input
(X42/1)
Analog Input
(X42/3)
Analog Input
(X42/5)
ECB option status nvoECBstatus
Parameter access
cmd.
Variable name SNVT type
nvoStatusword SNVT_state
SNVT_lev_percent
SNVT_freq_hz
nvoDrvEnrg SNVT_elec_kwh_l
nvoDCVoltage SNVT_volt
nvoTempMtr SNVT_lev_cont
SNVT_lev_cont
nvoFeedback SNVT_count_inc_f
nvoBrokenBelt SNVT_switch
nvoAlarm SNVT_switch
nvoWarning SNVT_switch
nvoAlarmword SNVT_state_64
nvoWarningword SNVT_state_64
nvoExtendedStsw SNVT_state_64
nvoDigitInput SNVT_state_64
SNVT_volt/
SNVT_amp_mil
SNVT_volt/
SNVT_amp_mil
nvo101AnIn1 SNVT_volt
nvo101AnIn2 SNVT_volt
nvo109AnIn1 SNVT_volt/
SNVT_temp_p
nvo109AnIn2 SNVT_volt/
SNVT_temp_p
nvo109AnIn3 SNVT_volt/
SNVT_temp_p
SNVT_state
nvoParamRes- UNVT_param_response
ponse
