5. Configuration of the system
Analog Input (54)
Variable
name:
nvoAnIn1
This variable contains the value allocated to the analog input terminal 54.
This terminal can either be configured as a voltage input (0-10 V) or as a current input (0-20 mA),
depending on the setting of switch S 202. The variable type is changeable with the commissioning
tool in order to match the appropriate unit.
5
Analog Input (X30/11)
Variable
name:
nvo101AnIn1
This variable contains the value allocated to the analog input terminal X30/11 of the
Purpose I/O option
Analog Input (X30/12)
Variable
name:
nvo101AnIn2
This variable contains the value allocated to the analog input terminal X30/11 of the
Purpose I/O option
Analog Input (X42/1)
Variable
name:
nvo109AnIn1
32
SNVT
type:
Changeable
SNVT_volt
SNVT_amp_mil
SNVT
type:
SNVT_volt
.
NB!
This variable is available only if the General Purpose I/O option (MCB 101) has been
installed.
SNVT
type:
SNVT_volt
.
NB!
This variable is available only if the General Purpose I/O option (MCB 101) has been
installed.
SNVT
type:
Changeable
SNVT_volt
SNVT_temp_p
MG.11.E1.02 - VLT
Value:
Min. Max.
0 V 10 V
0 mA 20 mA
Value:
Min. Max.
0 V 10 V
Value:
Min. Max.
0 V 10 V
Value:
Min. Max.
0 V 10 V
-273.15 °C 327.66 °C
® is a registered Danfoss trademark
VLT® FC 100 LonWorks
Resolution:
0.1 V
0.1 mA
Resolution:
0.1 V
General
Resolution:
0.1 V
General
Resolution:
0.1 V
0.01 °C
