VLT® FC 100 LonWorks
Analog Output (X30 / 8)
Variable
name:
nvi101AnOut1
This variable controls the X30/8 analog output on the General Purpose I/O option 0-20 mA or 4-20
mA.
In order to control output X30/8 via LonWorks, par. 6-60
one of the following options:
[139] Bus ctrl. 0-20 mA
[140] Bus crtl. 4-20 mA
[141] Bus crtl. 0-20 mA Timeout
[142] Bus crtl. 4-20 mA Timeout
Function:
Bus crtl. 0-20 mA [139]: The output is controlled via bus. In the event of bus timeout, the output
level remains unchanged.
Bus crtl. 4-20 mA [140]: The output is controlled via bus. In the event of bus timeout, the output
level remains unchanged.
Bus crtl. 0-20 mA [141]: The output is controlled via bus. In the event of bus timeout, the output
level is set to the predefined level in par. 6-64.
Bus crtl. 4-20 mA [142]: The output is controlled via bus. In the event of bus timeout, the output
level is set to the predefined level in par. 6-64.
Analog Output (X42 / 7)
Variable
name:
nvi109AnOut1
Analog Output (X42 / 9)
Variable
name:
nvi109AnOut2
Analog Output (X42 /11)
Variable
name:
nvi109AnOut3
SNVT
type:
SNVT_lev_per-
cent
NB!
This output variable applies only if the General Purpose I/O option is installed in the
frequency converter.
SNVT
type:
SNVT_lev_percent
SNVT
type:
SNVT_lev_percent
SNVT type:
SNVT_lev_percent
