Example 6–69. Final Assembly Code for FIR Filter With Redundant Load Elimination
and No Memory Hits
MVK
MVK
|| MVK
OUTLOOP:
LDH
|| ADD
|| ADD
|| MVK
||[A2] SUB
LDH
|| LDH
|| ZERO
|| ZERO
LDH
|| LDH
LDH
|| LDH
LDH
|| LDH
||[B2] SUB
LDH
|| LDH
LDH
|| LDH
MPY
|| MPY
|| LDH
|| LDH
[B2] B
|| MPY
|| MPY
|| LDH
|| LDH
||[B2] SUB
ADD
|| MPY
|| MPY
|| LDH
|| LDH
.S1 50,A2
.S1 62,A3
.S2 64,B10
.D1 *A4++,B5 ; x0 = x[j]
.L2X A4,4,B1
.L1X B4,2,A8
.S2 8,B2
.S1 A2,1,A2
.D2 *B1++[2],B0
.D1 *A4++[2],A0
.L1 A9
.L2 B9
.D1 *A8++[2],B6
.D2 *B4++[2],A1
.D1 *A4++[2],A5
.D2 *B1++[2],B5
.D2 *B4++[2],A7
.D1 *A8++[2],B8
.S2 B2,1,B2
.D2 *B1++[2],B0
.D1 *A4++[2],A0
.D1 *A8++[2],B6
.D2 *B4++[2],A1
.M1X B5,A1,A0
.M2X A0,B6,B6
.D1 *A4++[2],A5
.D2 *B1++[2],B5
.S1 LOOP
.M2 B0,B6,B7
.M1 A0,A1,A1
.D2 *B4++[2],A7
.D1 *A8++[2],B8
.S2 B2,1,B2
.L1 A0,A9,A9
.M2X A5,B8,B8
.M1X B0,A7,A5
.D2 *B1++[2],B0
.D1 *A4++[2],A0
; set up outer loop counter
; used to rst x pointer outloop
; used to rst h pointer outloop
; set up pointer to x[j+2]
; set up pointer to h[1]
; set up inner loop counter
; decrement outer loop counter
; x2 = x[j+i+2]
; x1 = x[j+i+1]
; zero out sum0
; zero out sum1
; h1 = h[i+1]
; h0 = h[i]
; x3 = x[j+i+3]
; x0 = x[j+i+4]
; h2 = h[i+2]
; h3 = h[i+3]
; decrement loop counter
;* x2 = x[j+i+2]
;* x1 = x[j+i+1]
;* h1 = h[i+1]
;* h0 = h[i]
; x0 * h0
; x1 * h1
;* x3 = x[j+i+3]
;* x0 = x[j+i+4]
; branch to loop
; x2 * h1
; x1 * h0
;* h2 = h[i+2]
;* h3 = h[i+3]
;* decrement loop counter
; sum0 += x0 * h0
; x3 * h3
; x2 * h2
;** x2 = x[j+i+2]
;** x1 = x[j+i+1]
