Example 6–28. Assembly Code for Fixed-Point Dot Product (Software Pipelined
With No Extraneous Loads) (Continued)
LOOP:
ADD .L1
|| ADD .L2
|| MPY .M1X
|| MPYH .M2X
||[A1] SUB .S1
||[A1] B .S2
|| LDW .D1
|| LDW .D2
; Branch occurs here
ADD .L1
|| ADD .L2
|| MPY .M1X
|| MPYH .M2X
ADD .L1
|| ADD .L2
|| MPY .M1X
|| MPYH .M2X
ADD .L1
|| ADD .L2
|| MPY .M1X
|| MPYH .M2X
ADD .L1
|| ADD .L2
|| MPY .M1X
|| MPYH .M2X
ADD .L1
|| ADD .L2
|| MPY .M1X
|| MPYH .M2X
ADD .L1
|| ADD .L2
ADD .L1
|| ADD .L2
ADD .L1X
A6,A7,A7 ; sum0 += (ai * bi)
B6,B7,B7 ; sum1 += (ai+1 * bi+1)
A2,B2,A6 ;** ai * bi
A2,B2,B6 ;** ai+1 * bi+1
A1,1,A1 ;****** decrement loop counter
LOOP ;***** branch to loop
*A4++,A2 ;******* ld ai & ai+1 fm memory
*B4++,B2 ;******* ld bi & bi+1 fm memory
A6,A7,A7 ; sum0 += (ai * bi)
B6,B7,B7 ; sum1 += (ai+1 * bi+1)
A2,B2,A6 ;** ai * bi
A2,B2,B6 ;** ai+1 * bi+1
A6,A7,A7 ; sum0 += (ai * bi)
B6,B7,B7 ; sum1 += (ai+1 * bi+1)
A2,B2,A6 ;** ai * bi
A2,B2,B6 ;** ai+1 * bi+1
A6,A7,A7 ; sum0 += (ai * bi)
B6,B7,B7 ; sum1 += (ai+1 * bi+1)
A2,B2,A6 ;** ai * bi
A2,B2,B6 ;** ai+1 * bi+1
A6,A7,A7 ; sum0 += (ai * bi)
B6,B7,B7 ; sum1 += (ai+1 * bi+1)
A2,B2,A6 ;** ai * bi
A2,B2,B6 ;** ai+1 * bi+1
A6,A7,A7 ; sum0 += (ai * bi)
B6,B7,B7 ; sum1 += (ai+1 * bi+1)
A2,B2,A6 ;** ai * bi
A2,B2,B6 ;** ai+1 * bi+1
A6,A7,A7 ; sum0 += (ai * bi)
B6,B7,B7 ; sum1 += (ai+1 * bi+1)
A6,A7,A7 ; sum0 += (ai * bi)
B6,B7,B7 ; sum1 += (ai+1 * bi+1)
A7,B7,A4 ; sum = sum0 + sum1
Optimizing Assembly Code via Linear Assembly
Software Pipelining
ADDs MPYs
1
1
2
2
3
3
4
4
5
5
6
7
