AT Command Set

6.2 AT^MONI Monitor idle mode and dedicated mode

Test command Response
AT^MONI=? ^MONI: (list of supported < period > s) OK
Write command
This command can be used to retrieve, automatically every n seconds, information
on the serving/dedicated cell. The display can be terminated by any character sent
AT^MONI[=<pe
to serial port except if autobauding is enabled (+IPR=0). Then type character ´a´ to
riod>]
abort.
Note:
The two header lines (see below) are output after every ten data lines.
Response
See execute command
Parameter
<period>
Execute command This command can be used to retrieve, on request, the cell parameters of the
AT^MONI
serving/dedicated cell.
Note:
The length of following output lines exceeds 80 characters. Therefore a terminal
program may draw a carriage return on a screen. However, this is not part of the
response.
Response (Examples)
ME is not connected:
a) ME is camping on a cell
Serving Cell
chann rs dBm PLMN
1013 21 -71 00101 1001 0103
b) ME camping on a cell, but searching for a better cell (cell reselection)
Serving Cell
chann rs dBm PLMN
1013 4 –106 00101 1001 0103
c) ME is not camping on a cell and could not (yet) find a suitable cell
Serving Cell
chann rs dBm PLMN
ME is connected:
Serving Cell
chann rs dBm PLMN
1013 19 -76 00101 1001 0103
Parameters
Serving Cell:
chann
rs
dBm
PLMN
LAC
cell
NCC
BCC
PWR
RXLev
C1
TC3X_ATC_01_V04.00
1 – 254 Display period in seconds
LAC cell NCC BCC PWR RXLev
7 7 33
LAC cell NCC BCC PWR RXLev
7 7 33
LAC cell NCC BCC PWR RXLev
LAC cell NCC BCC PWR RXLev
7 7 33
ARFCN (Absolute Frequency Channel Number) of the BCCH carrier
RSSI (Received signal strength) of the BCCH carrier from 0 to 63. The
indicated value is composed of the measured value in dBm plus an
offset. This is in accordance with a formula specified in 3GPP TS 05.08.
receiving level of the BCCH carrier in dBm
PLMN ID code
location area code, see note below.
cell ID, see note below.
PLMN colour code
base station colour code
maximal power level used on RACH channel in dBm.
minimal receiving level (in dBm) to allow registration
coefficient for base station selection
Page 144 of 204
I Dedicated channel
C1 I chann TS timAdv PWR
-105 33 I No connection
I Dedicated channel
C1 I chann TS timAdv PWR
-105 -1 I in Reselecting
I Dedicated channel
C1 I chann TS timAdv PWR
I Dedicated channel
C1 I chann TS timAdv PWR
-105 33 I 1015 1
dBm Q ChMod
dBm Q ChMod
dBm Q ChMod
dBm Q ChMod
0 5 -76 0 S_HR
