Danfoss VLT AQUA Drive Design Manual page 44

3. VLT AQUA Selection
Normal overload 110% for 1 minute
Line supply 200-240 V AC.
Adjustable frequency drive
Typical Shaft Output [kW]
Typical Shaft Output [HP] at 208 V
Encapsulation
IP 20
IP 55
3
IP 66
Output current
Max. input current
1.
2.
3.
4.
44
Continuous
(3 x 200-240 V) [A]
Intermittent
(3 x 200-240 V) [A]
Continuous
kVA (208 V AC) [kVA]
Max. cable size:
(line, motor, brake)
2
[mm /AWG]
Continuous
(3 x 200-240 V) [A]
Intermittent
(3 x 200-240 V) [A]
Max. pre-fuses
Environment
Estimated power loss
at rated max. load [W]
Weight enclosure IP 20 [kg]
Weight enclosure IP 21 [kg]
Weight enclosure IP 55 [kg]
Weight enclosure IP 66 [kg]
4)
Efficiency
For type of fuse, see section Fuses.
American Wire Gauge
Measured using 16.4 ft. [5 m] shielded motor cables at rated load and rated frequency.
The typical power loss is at nominal load conditions and expected to be within +/-15%
(tolerance relates to variety in voltage and cable conditions).
Values are based on a typical motor efficiency (eff2/eff3 border line). Lower efficiency
motors will also add to the power loss in the adjustable frequency drive and vice versa.
If the switching frequency is raised from nominal, the power losses may rise significantly.
LCP and typical control card power consumption values are included. Further options and
customer load may add up to 30W to the losses (though typically only 4W extra for a
fully loaded control card, or options for slot A or slot B, each).
Although measurements are made with state of the art equipment, some measurement
inaccuracy must be allowed for (+/- 5%).
MG.20.N2.22 - VLT
P1K1 P1K5
1.1 1.5
1.5 2
A2 A2
A5 A5
A5 A5
6.6 7.5
7.3 8.3
2.38 2.70
5.9 6.8
6.5 7.5
1) 20 20
[A]
63 82
4)
4.9 4.9
5.5 5.5
13.5 13.5
13.5 13.5
0.96 0.96
