Software

6.1

Overview

This chapter provides the software-related information for the PCIE-7217.
6.2

Management CPU Software

The PCIE-7217 software is based on CentOS 7.x Linux distribution. It runs on both the
Management CPU (mCPU) and the Application CPU (aCPU).
A service is started on the mCPU, which exposes an interface for you to configure the PCI
switch of the MC4100 system. This service is called MaxCore Configuration Service
(MCCS).
In addition to that, the software delivery includes tools to upgrade the firmware of the CPU
and CPLD and tools to debug the system.
The kernel supports the following features:
 Unprotect the BIOS flash, when a full flash upgrade is necessary

Disable the PCIe Power Management, which is not supported by the PCI switch
The root file system provides a minimal server installation and includes SSH, DHCP, TFTP,
iSCSI, and libvirt supporting KVM and QEMU. A DPDK package is also available.
6.2.1

Installing Linux

The software release contains files to boot from a USB, boot from network, and install to
disk. The following table contains the list of files in the delivery package.
.
Table 6-1
Directory
EFI
isolinux
images
PCIE-7217 Installation and Use (6806873A01B)
List of Files in Delivery Package
File
BOOT
kernel
ramfs.xz
files.shalsum
Description
To booth into UEFI mode
To boot into legacy mode
Kernel image file used for USB, PXEboot or disk booting
initramfs based root file system
Sha1sum of vmlinuz and ramfs.xz are used during
the installation on to the disk
