Figure 4-4 Location of On-board SSD Activity LED for CPU2 (D6)

Table 4-5
Label
D13
D6
PCIE-7217 Installation and Use (6806873A01B)
CPU1
On-board SSD Activity LEDs
Color
Green
Green
Controls, Indicators, and Connectors
D6
(CPU2)
Status Description
CPU1 on-board SSD activity
CPU2 on-board SSD activity
CPU2
71
