5.3.5

Boot Menu

To view the Boot menu, select the Boot tab on the menu bar. The Boot menu screen is
displayed as shown below.

Figure 5-9 Boot Menu

The following table provides options in the Boot menu and their default settings.
The values shown in the tables enclosed within brackets [...] indicate the
default settings.
Table 5-7
Feature
Boot Type
Quick Boot
PCIE-7217 Installation and Use (6806873A01B)
Boot Menu
Option [Default] Description
Dual Boot Type
Legacy Boot Type
[UEFI Boot Type]
[Enabled]
Disabled
NOTICE
Selects the boot type
Enables or disables the quick boot feature which skip
certain tests to decrease the boot time
BIOS
89
